AP-6511 Access Point Installation Guide
30
4.3 AP-6511 Radio Characteristics
An AP-6511 model Access Points has the following radio characteristics:
Operating Channels All channels from 5180 MHz to 5825 MHz
Channels 1-13 (2412-2472 MHz)
Actual operating frequencies depend on regulatory approval for the
country of use.
Data Rates Supported 802.11b: 1Mbps, 2Mbps, 5.5Mbps and 11Mbps
802.11g: 6Mbps, 9Mbps, 12Mbps, 18Mbps, 24Mbps, 36MBps,
48Mbps and 54Mbps
802.11n: MCS0 through MCS15, HT20 and HT40
Wireless Medium Direct Sequence Spread Spectrum (DSSS),
Orthogonal Frequency Division Multiplexing (OFDM)
Spatial multiplexing (MIMO)
Network Standards 802.11a, 802.11b, 802.11g, 802.3, 802.11n
Typical Transmit
Power Per Antenna
2.4G: +24dBm max
5.2G: +22dBm max
Transmit Power
Adjustment
1dB increments
