AP-6511 Access Point Installation Guide
6
• Ensure the cable length from the Ethernet source (host) to the Power Injector and AP-6511
Access Point does not exceed 100 meters (333 ft).
2.5 Wall Mount Installation
To support wall mount installations, the metal mounting plate (provided with the AP-6511) is fastened
to a flat wall surface. The wall should be of gypsum board, plaster, wood or concrete in composition.
To install an AP-6511 model Access Point to a wall surface:
1. Attach the metal mounting plate (shipped with the AP-6511) to a wall surface at the desired
deployment location.
CAUTION To avoid problematic performance and restarts, disable POE from a
wired controller port connected to an Access Point if mid-span power
sourcing equipment (PSE) is used between the two, regardless of the
manufacturer.
CAUTION Ensure AC power is supplied to the Power Injector using an AC cable
with an appropriate ground connection approved for the country of
operation.
NOTE Motorola recommends the following customer supplied mounting
accessories an AP-6511 wall mount installation:
2, screws, #6 x 2.00 inch pan head
2, wall anchors suitable for the #6 screws
!
!
