Specifications
29
4 Specifications
4.1 AP-6511 Electrical Characteristics
An AP-6511 model Access Point has the following electrical characteristics:
4.2 AP-6511 Physical Characteristics
An AP-6511 model Access Point has the following physical characteristics:
Operating Current &
Voltage
250mA@48VDC
Dimensions 2.75 width x 5 height x 1.25 deep (Inches)
6.985 width x 12.7 height x 3.175 deep (centimeters)
Housing Plastic and metal
Weight 0.5 lbs (with mounting plate)
Operating
Temperature
32°F to 104°F/0°C to 40°C
Storage Temperature -40°F to 158°F/-40°C to 85°C
Operating Humidity 5 to 95% Relative Humidity non-condensing
Storage Humidity 95% Relative Humidity non-condensing
Operating Altitude
(max)
8,000 ft @ 28°C
Storage Altitude
(max)
30,000 ft @ 12°C
Electrostatic
Discharge
+/-15kV Air and +/-8kV Contact @ 50% Relative Humidity
