Hardware Installation
23
2.5.4 Single Radio 5 Ghz AP-7131 LEDs
A single 5 Ghz radio model has the following unique LED behavior:
LED 1 LED 2 LED 3 LED 4 - 5 GHz LED 5 - 2.4 GHz LED 6
Blinking Red
indicates
booting. Solid
Red defines the
diagnostic
mode. White
defines normal
operation.
Green defines
normal GE1
operation.
Green defines
normal GE2
operation.
Blinking
Amber
indicates
802.11a activity.
A 5 second
Amber and
Yellow blink
rate defines
802.11an
activity.
A 2 second
Amber and
Yellow blink
rate defines
802.11an
(40 MHz)
activity.
When
functioning as a
sensor, LED
alternates
between
Amber and
Yellow.
The blink
interval is 0.5
seconds. It’s 1
second when no
Server is
connected.
Off Not Used
