AP-7131 Series Access Point: Installation Guide
24
2.5.5 Rear AP-7131 LED
The LED on the rear (bottom) of the access point is optionally viewed using a single (customer
installed) extended light pipe, adjusted as required to suit above the ceiling installations. The LED
light pipe has the following color display and functionality
3 Basic Configuration
For the basic setup described in this guide, the Java-based Web UI will be used to configure the
access point. To access the access point via the GE1/POE port, the GE1/POE port default setting is
DHCP client. For this example, the access point’s WAN interface will be used to connect to the access
point. The default WAN IP address is 10.1.1.1. For optimal viewing of the Web UI, the screen
resolution should be set to 1024 x 768 pixels or greater.
1. Start a browser and enter the following IP address in the address field:
https://10.1.1.1
LED 7
Blinking Red (160 msec) indicates a failure condition.
Solid Red defines the diagnostic mode.
White defines normal operation.
NOTE For advanced configuration options beyond the scope of this guide, refer
to the AP-7131 Series Product Reference Guide. The guide is available on
the Motorola Web site, at
h
ttp://support.symbol.com/support/product/manuals.do.
NOTE For optimum compatibility, use Sun Microsystems’ JRE 1.5 or higher
(available from Sun’s Website), and be sure to disable Microsoft’s Java
Virtual Machine if installed.
NOTE The computer being used should be configured to use the same
IP address and subnet mask as the access point.
