Motorola AP 7161 User Manual

Installation Guide 11
1.4 Outdoor PoE Hardware and Mounting Accessories
The AP 7161 is a Power over Ethernet (PoE) device. When deployed, the use of an outdoor rated PoE power supply
and mounting bracket may be required. The recommended Motorola Solutions PoE accessories are listed in the
following table. For more information, see
AP 7161 Power Options Using Power over Ethernet on page 45.
1.5 AP 7161 Mounting Accessories
The AP 7161 has a flexible three piece mounting kit ( KT-147407-01) , together with an optional standoff extension
arm (
KT-150173-01) for pole mounting. When deployed as a VMM, use the vehicle mount kit ( KT-158767-01). For more
information, see
AP 7161 Hardware Mounting and Installation on page 23.
1.6 AP 7161 Weatherized Ethernet Accessory
One RJ45 weatherized connector plug is included with each AP 7161 Access Point. If additional plugs are
required, they can be ordered using the part number listed in the following table:
Part Number Description
AP-PSBIAS-7161-US Outdoor IP66 802.3AT gigabit Ethernet power injector, 100-240 VAC US
AP-PSBIAS-7161-WW Outdoor IP66 802.3AT gigabit Ethernet power injector, 100-240 VAC
International
KT-153143-01 Outdoor PoE mounting kit
Part Number Description
KT-147407-01 AP 7161 mounting hardware kit
KT-150173-01 AP 7161 12 inch extension arm for mounting kit
KT-158767-01 AP 7161 vehicle mount
Part Number Description
KT-153676-01 AP 7161 RJ45 weatherized Ethernet plug
