Page #9 background imageLoading...
Page #9 background image
Installation Guide 9
1.3.1 AP 7161 4.9 GHz and 5 GHz Antennas
1.3.2 AP 7161 Multi Band Antennas
Part Number Band Gain
Height
(inches)
Description
ML-5299-HPA10-01 4.9-5.8 10 19.5 Outdoor rated
Type: dipole
Gain: 10dBi@4.9GHz
Connector: N-male
ML-5299-HPA5-01 5.2-5.8 5 6.75 Outdoor rated
Type: dipole
Gain: 5dBi@5.0GHz
Connector: N-male
ML-5299-FHPA6-01 4.9-5.8 8 11 Outdoor rated
Type: dipole
Gain: 8dBi@4.9-5.8GHz
Connector: N-male
Part Number Band Gain
Height
(inches)
Description
ML-2452-HPAG5A8-01 2.4-5.8 4.5/7.5 11 Outdoor rated
Type: dipole
Gain: 4.5dBi@2.4GHz, 7.5dBi@5GHz, 5.5dBi@4.9GHz
Connector: N-male
ML-2452-VMM3M3-036 2.4-5.8 3.6/4.0 1.5 Outdoor rated
Vehicle Mounted MIMO Omni Patch
Type: VMM
Gain: 3.6dBi (typical) to 4.5dBi (maximum) @2.4GHz,
4.5 (typical) to 5.4 (maximum) @5.8GHz
Connector: RP-SMA male
NOTE The ML-2452-HPAG5A8-01 multi band antenna is suggested for use with AP 7161
sensor models AP-7161-66S40-US and AP-7161-66S40-WR on ports R3-A and R3-B,
respectively. The
ML-2452-VMM3M3-036
is suggested for use with AP 7161 VMM. Three
connections to the radio on either R1 or R2 are required for mobile operation.
