10 AP-8132 Access Point
To install the Power Injector to an Ethernet data source and an access point:
1. Connect the Power Injector to an AC outlet (110VAC to 220VAC).
2. Connect an RJ-45 Ethernet cable between the network data supply (host) and the Power Injector Data In
connector.
3. Connect an RJ-45 Ethernet cable between the Power Injector Data & Power Out connector and the
access point’s GE1/POE port.
Ensure the cable length from the Ethernet source (host) to the Power Injector and access point does not
exceed 100 meters (333 ft).
The Power Injector has no On/Off power switch. The Injector receives power and is ready for device
connection and operation as soon as AC power is applied. Refer to the Installation Guide shipped with the
Power Injector for a description of the device’s LEDs.
2.5 Wall Mount Instructions
A wall mount deployment requires hanging the AP-8132 access point along its width or length using two of three
slots on the bottom of the unit. The AP-8132 can be mounted on to any plaster, wood or cement wall surface using
the provided wall anchors.
The hardware required to install the AP-8132 on a wall consists of:
• Two wide-shoulder Phillips pan head self-tapping screws (M3.5 x 0.6 x 23 mm)
• Two wall anchors
• Security cable (optional)
Optional customer provided installation tools include:
• Security cable
• Philips head screw driver, or drill and drill bit
CAUTION To avoid problematic performance and restarts, disable POE from a
wired switch port connected to an access point if mid-span power
sourcing equipment (PSE) is used between the two, regardless of the
manufacturer of the switch.
CAUTION Ensure AC power is supplied to the Power Injector using an AC cable
with an appropriate ground connection approved for the country of
operation.
CAUTION Cabling a Power Injector to the WAN port (GE2 port) renders the AP
non-operational. Only use a AP-PSBIAS-2P3-ATR Power Injector with
the access point’s GE1/POE (LAN) port.
!
!
!
