Installation Guide 7
2 Hardware Installation
2.1 Installation Instructions
An AP-8132 access point mounts either on a wall (with M4 x 25 pan head screws and wall anchor - or equivalent)
or on a suspended ceiling T-bar.
Once the AP-8132 is installed with facade and cabled, the cables (Ethernet and module connections) should not be
visible when looking directly at the unit (ceiling and wall mounts).
To prepare for the installation:
1. Match the model number on the purchase order with the model numbers in the packing list and on the
case of the access point.
2. Verify the contents of the box include the intended AP-8132 access point, and the included hardware
matches the package contents on page 4.
3. Review site survey and network analysis reports to determine the location and mounting position for the
AP-8132 access point.
4. Connect a CAT-5 or better Ethernet cable to a compatible 802.3at or 802.3af power source and run the
cable to the installation site. Ensure there is sufficient slack on the cable to perform the installation
steps.
2.2 Precautions
Before installing an AP-8132 model Access Point, verify the following:
• Your using the correctly rated power solution for the AP-8132 (either the AP-PSBIAS-2P3-ATR power
injector or the PWRS-14000-247R external power supply)
• Motorola Solutions recommends you do not to install the AP-8132 in wet or dusty areas.
• Verify the environment has a continuous temperature range between 0° C to 50° C.
2.3 Access Point Placement
For optimal performance, install the access point away from transformers, heavy-duty motors, fluorescent lights,
microwave ovens, refrigerators and other industrial equipment. Signal loss can occur when metal, concrete, walls
Part Number Description
AP-8132-66040-US 802.11n 3x3:3 access point dual radio US version
AP-8132-66040-WR 802.11n 3x3:3 access point dual radio non-US (rest of world) version
AP-8132-66040-EU 802.11n 3x3:3 access point dual radio European version
NOTE When operating in a Gigabit Ethernet environment, CAT-5e or CAT-6 cable
is recommended for Gigabit operation.
