When the key has been loaded successfully, one of
the following scenarios occurs:
• You hear a short tone for single-key radios.
• You hear an alternating tone for multikey radios.
Multikey Feature
This feature allows the radio to be equipped with
different encryption keys and supports the DES-OFB
algorithm.
There are two types:
Conventional
Multikey
The encryption keys can be tied
(strapped), on a one-per-channel
basis, through Customer
Programming Software. In addition,
you can have operator-selectable
keys, operator-selectable keysets,
and operator-selectable key
erasure. If talkgroups are enabled
in conventional, then the encryption
keys are strapped to the talkgroups.
Trunked
Multikey
If you use your radio for both
conventional and trunked
applications, you have to strap your
encryption keys for trunking on a
per-talkgroup or announcement-
group basis. In addition, you may
strap a different key to other
features, such as dynamic
regrouping, failsoft, or emergency
talkgroup. You can have operator-
selectable key erasure.
Selecting an Encryption Key
1
or to Key.
2
Press the Menu Select button directly below Key.
The display shows the last user-selected and
stored encryption key, and the available menu
selections.
3 or to scroll through the encryption keys or
use the keypad to enter the number of the desired
key.
4 Perform one of the following actions:
• Press the Menu Select button directly below
Sel to save the newly selected key and return
to the Home screen.
Advanced Features
122
English

Motorola APX 2000 Specifications

General

IP Rating	IP67
Operating Temperature	-30°C to +60°C
GPS	Optional
Bluetooth	No
Frequency Range	700/800 MHz
Power Output	1-5 W (VHF), 1-3 W (700/800 MHz)
Channels	Up to 1, 000
Battery Life	Up to 10 hours (digital)
Digital Protocol	APCO P25
Frequency	VHF: 136-174 MHz, UHF: 380-470 MHz, 700/800 MHz: 764-870 MHz
Power	1-3W (700/800 MHz), 1-5W (VHF)
