Motorola APX 2000 User Manual

9
Press the Menu Select button directly below Send
or press the PTT button to send the message.
The display shows the Send Message screen and
Sending msg.
If the message is sent, you hear a tone and the
display shows Msg sent.
If the message is not sent, you hear a low tone,
the display shows Send failed and returns to the
main TMS screen.
Note: You can append a priority status and/or a
request reply to your message. See Priority Status
and Request Reply of a New Text Message on
page 108 for more information.
You can also select the Save to Drafts option to
save your message in the Drafts folder to send it
at a later time. See Accessing the Drafts Folder on
page 113 for more information.
Sending a Quick Text Message
Quick Text messages are messages that are
predefined and usually consist of messages that are
used most frequently.
Each Quick Text message or Query has a maximum
length of 50 characters. You can select the required
text from the Quick Text or Query.
1 Perform one of the following actions:
• To access this feature via a preprogrammed
button, press the preprogrammed Quick Text
button and proceed to Step 4.
• To access this feature via the menu, proceed
to the next step.
2
or to TMS and press the Menu Select button
directly below TMS to access the TMS feature
screen.
3 Perform one of the following actions:
•
or to Compose and press the Menu
Select button directly below Sel.
• Press the Menu Select button directly below
Exit to return to the Home screen.
4
or to Quick Text and press the Menu
Select button directly below Sel for a predefined
message.
Advanced Features
107
English

Motorola APX 2000 Specifications

General

IP Rating	IP67
Operating Temperature	-30°C to +60°C
GPS	Optional
Bluetooth	No
Frequency Range	700/800 MHz
Power Output	1-5 W (VHF), 1-3 W (700/800 MHz)
Channels	Up to 1, 000
Battery Life	Up to 10 hours (digital)
Digital Protocol	APCO P25
Frequency	VHF: 136-174 MHz, UHF: 380-470 MHz, 700/800 MHz: 764-870 MHz
Power	1-3W (700/800 MHz), 1-5W (VHF)
