MENU SELECT, HOME, AND 4-WAY NAVIGATION BUTTONS:
On the front of the radio, immediately below the main
display, are a series of buttons.
The first set consists of three small buttons, each with a dot
or series of dots. These buttons are called the menu select
buttons and correspond to the menu option the screen above
them is showing. For instance, in the example on the left
pressing the middle button would bring up the zone menu.
Below the menu select buttons are another series of buttons.
The button with the small house on it is called the home
button. Pressing this button acts like an escape button on a
computer. If you are lost deep in a menu a short press on the
home button will bring you back to the default menu screen
(Zone Down/Zone/Zone Up). If have no idea how to get back
to your home talk-group, a long press on the home button will
take you back to your home talk-group as set in the initial
programming, Fire-1 for fire and Police-2 for Police.
The large button in the center is the 4-way navigation
button. This button allows you to navigate through the
various menus on the radio.
On the right is the future use/computer button. This button
has no current use.
Menu
Select
Buttons
Home
Button
4-Way Navigation Button
“Future Use”
FC ZONE A DG
POLICE 2
