Motorola APX 4000 Guide

APX 6000 Nomenclature—FRONT
NUMBER DESCRIPTION NUMBER DESCRIPTION
1
Antenna
8
Battery Latch
APX 6000
APX 4000 has battery latch on bottom of battery.
2
Multi-Color LED
9
Keypad (Model 3 Only)
3
Emergency Button
At least 1 second push to activate.
At least 2 second push to reset
10
Computer Icon / “Future Use”
4
Front Microphone
11
Menu Select Buttons
5
Accessory / Shoulder
Microphone Connector
12
Main Display
6
Home Button
13
Encryption on/off
Not Used
APX 6000 only
7
4-Way Navigation Buttons
Used to navigate through the
menu functions.
14
Multi position “A”, “B”, “C” switch
Keypad lock in position “C”.
Position “A” and “B” have no function.
APX 6000 only

Motorola APX 4000 Specifications

General

IP Rating	IP67
Operating Temperature	-30°C to +60°C
GPS	Optional
Frequency Range	VHF: 136-174 MHz, UHF: 380-470 MHz, 450-520 MHz
Power Output	VHF: 1-5W; UHF: 1-4W
Digital Protocol	APCO P25
Dimensions	5.2 x 2.4 x 1.5 inches (without battery)
