CLP446e
5
Models and CLPe PLUS Models
Channel LED Status Color
14 White
White
15 Aqua
White
16 Orange
White
NOTE: Channel 9 to 16 is enabled through Customer Programming Software (CPS)
configuration.
2.8.2
LED Indicators
Feature LED Indicator
Monitor mode Solid per channel color.
Call tone Momentary solid per channel color.
Scan LED slowly displays all current channel colour one after
another.
Turn on or off Solid red for 2 seconds
Advanced radio configuration Blinking green.
2.8.2.1
Volume LED
When volume is increased, Smart Status Glow Ring LED lights up in a clockwise direction from the
bottom left to the bottom right of the LED ring.
The followings are the three levels of LED brightness for each LED when volume is increased:
• Dim
• Medium
• Maximum brightness
5
Where permitted by local country law. Restricted to 8 channels in Russia by law.
MN006181A01-AC
Chapter 2 : Getting Started
