Motorola EP350

13-15 Circuit Board/Schematic Diagram and Parts List (UHF1: 403–447 MHz)
C512 TDK N/A Chip Cap,1005 K 470PF
C515 TDK N/A Chip Cap,1005 Z 0.1μF
C516 HITACH N/A Chip Tantal, 10μF-M/16V(A)
C517 TDK N/A Chip Cap,1005 K 15nF
C518 TDK N/A Chip Cap, 1005 K 5.6nF
C519 TDK N/A Chip Cap, 1005 K 1.2nF
C520 TDK N/A Chip Cap, 1005 K 6.8nF
C521 TDK N/A Chip Cap, 1005 K 1.2nF
C522 TDK N/A Chip Cap, 1005 K 8.2nF
C523 TDK N/A Chip Cap,1005 K 470PF
C524 TDK N/A Chip Cap,1005 K 47nF
C525 TDK N/A Chip Cap, 1005 K 3.3nF
C527 TDK N/A Chip Cap, 1005 K 18nF
C528 TDK N/A Chip Cap, 1005 K 18nF
C529 TDK N/A Chip Cap,1005 Z 0.1μF
C530 TDK N/A Chip Cap,1005 K 10nF
C531 TDK N/A Chip Cap,1005 Z 0.1μF
C533 TDK N/A Chip Cap,1005 Z 0.1μF
C536 TDK N/A Chip Cap,1005 K 15nF
C537 TDK N/A Chip Cap, 1005 K 2.2μF
C538 TDK N/A Chip Cap,1005 K 10nF
C539 HITACH N/A Chip Tantal, 10μF-M/16V(A)
C540 TDK N/A Chip Cap, 1608 Z 0.1μF
C541 TDK N/A Chip Cap,1005 Z 0.1μF
C542 TDK N/A Chip Cap,1005 K 10nF
C543 TDK N/A Chip Cap, 1005 K 8.2nF
C545 HITACH N/A Chip Tantal, 22μF-M/10V(A)
C546 TDK N/A Chip Cap,1005 K 0.1μF
C547 TDK N/A Chip Cap, 1005 K 2.2μF
C549 TDK N/A Chip Cap,1005 K 560PF
C550 TDK N/A Chip Cap,1005 K 560PF
C551 HITACH N/A Chip Tantal, 10μF-M/10V(A)
Circuit
Ref.
Supplier Supplier Part No. Description
C560 TDK N/A Chip Cap,1005 J 47PF
C561 TDK N/A Chip Cap,1005 J 47PF
C562 TDK N/A Chip Cap,1005 J 47PF
C563 TDK N/A Chip Cap,1005 J 47PF
C564 TDK N/A Chip Cap,1005 J 47PF
C565 TDK N/A Chip Cap,1005 J 47PF
C566 TDK N/A Chip Cap,1005 J 47PF
C570 TDK N/A Chip Cap,1005 J 47PF
C571 TDK N/A Chip Cap,1005 K 15nF
C572 TDK N/A Chip Cap,1005 Z 0.1μF
C573 TDK N/A Chip Cap,1005 J 47PF
C574 TDK N/A Chip Cap,1005 J 47PF
C575 TDK N/A Chip Cap,1005 J 47PF
C576 TDK N/A Chip Cap,1608 J 47PF
C577 TDK N/A Chip Cap,1005 J 47PF
C578 TDK N/A Chip Cap,1005 J 47PF
C579 TDK N/A Chip Cap,1005 J 47PF
C580 TDK N/A Chip Cap,1005 J 47PF
C581 TDK N/A Chip Cap,1005 J 47PF
C582 TDK N/A Chip Cap,1005 J 47PF
C583 TDK N/A Chip Cap,1005 J 47PF
C601 TDK N/A Chip Cap,1005 Z 0.1μF
C602 TDK N/A Chip Cap,1005 K 0.22μF
C605 TDK N/A Chip Cap, 2012 Z 4.7μF
C606 TDK N/A Chip Cap,1005 Z 0.1μF
C609 TDK N/A Chip Cap,1005 K 0.1μF
C615 TDK N/A Chip Cap, 1608 K 0.22μF
C616 TDK N/A Chip Cap,1005 K 0.1μF
C617 TDK N/A Chip Cap,1005 K 0.1μF
C618 HITACH N/A Chip Tantal, 4.7μF-M/16V(A)
C619 TDK N/A Chip Cap, 1005 J 33PF
C620 TDK N/A Chip Cap,1005 K 330PF
Circuit
Ref.
Supplier Supplier Part No. Description
C621 TDK N/A Chip Cap,1005 K 330PF
C622 TDK N/A Chip Cap, 1005 J 47PF
C623 TDK N/A Chip Cap, 1005 J 47PF
C624 TDK N/A Chip Cap, 1005 J 47PF
C625 TDK N/A Chip Cap, 1608 J 47PF
C701 HITACH N/A Chip Tantal, 22μF-M/10V(A)
C702 TDK N/A Chip Cap,1005 K 1nF
C704 TDK N/A Chip Cap,1005 K 1nF
C705 TDK N/A Chip Cap,1005 C 3PF
C706 TDK N/A Chip Cap, 1005 D 9PF
C707 TDK N/A Chip Cap, 1005 J 18PF
C709 TDK N/A Chip Cap, 1005 D 7PF
C710 MURATA N/A Chip Trimmer Cap, 2PIE 6PF
C711 MURATA N/A Chip Cap, 1005 J 16PF
C712 TDK N/A Chip Cap,1005 K 470PF
C714 TDK N/A Chip Cap,1005 K 1nF
C715 HITACH N/A Chip Tantal, 22μF-M/10V(A)
C716 TDK N/A Chip Cap,1005 K 470PF
C717 TDK N/A Chip Cap, 1005 C 3PF
C718 TDK N/A Chip Cap, 1005 C 4PF
C719 TDK N/A Chip Cap, 1005 D 7PF
C721 TDK N/A Chip Cap, 1005 C 3PF
C722 MURATA N/A Chip Trimmer Cap, 2PIE 6PF
C723 TDK N/A Chip Cap, 1005 C 0.5PF
C724 TDK N/A Chip Cap, 1005 J 12PF
C725 TDK N/A Chip Cap,1005 K 470PF
C726 TDK N/A Chip Cap,1005 C 1PF
C727 TDK N/A Chip Cap,1005 C 3PF
C728 TDK N/A Chip Cap,1005 C 5PF
C729 TDK N/A Chip Cap, 1005 D 6PF
C730 TDK N/A Chip Cap, 1005 C 2PF
C731 TDK N/A Chip Cap, 1005 C 2PF
Circuit
Ref.
Supplier Supplier Part No. Description
