Motorola EP350

Circuit Board/Schematic Diagram and Parts List (UHF1: 403–447 MHz) 13-20
R431 KAMAYA N/A Chip Res, 1005 J 10KW
R432 KAMAYA N/A Chip Res, 1005 J 27KW
R433 KAMAYA N/A Chip Res, 1005 J 0W
R434 KAMAYA N/A Chip Res, 1005 J 33KW
R435 KAMAYA N/A Chip Res, 1005 J 150W
R436 KAMAYA N/A Chip Res, 1005 J 100W
R440 KAMAYA N/A Chip Res, 1005 J 15KW
R441 KAMAYA N/A Chip Res, 1005 J 0W
R501 KAMAYA N/A Chip Res, 1005 J 220W
R502 KAMAYA N/A Chip Res, 1005 J 220W
R503 KAMAYA N/A Chip Res, 1005 J 56KW
R504 NOBLE N/A CHIP SEMI V.R, 3PIE 47 KW
R505 KAMAYA N/A Chip Res, 1005 J 12KW
R506 KAMAYA N/A Chip Res, 1005 J 10KW
R507 KAMAYA N/A Chip Res, 1005 J 10KW
R508 KAMAYA N/A Chip Res, 1005 J 3.6KW
R509 KAMAYA N/A Chip Res, 1005 J 2.2KW
R510 KAMAYA N/A Chip Res, 1005 J 15KW
R511 KAMAYA N/A Chip Res, 1005 J 8.2KW
R512 KAMAYA N/A Chip Res, 1005 J 20KW
R513 KAMAYA N/A Chip Res, 1005 J 10KW
R514 KAMAYA N/A Chip Res, 1005 J 15KW
R515 KAMAYA N/A Chip Res, 1005 J 20KW
R516 KAMAYA N/A Chip Res, 1005 J 2.7KW
R517 KAMAYA N/A Chip Res, 1005 J 5.6KW
R518 KAMAYA N/A Chip Res, 1005 J 4.7KW
R519 KAMAYA N/A Chip Res, 1005 J 4.7MW
R520 KAMAYA N/A Chip Res, 1005 J 1MW
R521 KAMAYA N/A Chip Res, 1005 J 330KW
R523 KAMAYA N/A Chip Res, 1005 F 30KW
R524 KAMAYA N/A Chip Res, 1005 F 47KW
R526 NOBLE N/A CHIP SEMI V.R, 2PIE 47 KW
Circuit
Ref.
Supplier Supplier Part No. Description
R527 KAMAYA N/A Chip Res, 1005 J 82KW
R528 KAMAYA N/A Chip Res, 1005 J 82KW
R529 KAMAYA N/A Chip Res, 1005 J 47KW
R530 KAMAYA N/A Chip Res, 1005 J 47KW
R531 KAMAYA N/A Chip Res, 1005 J 47KW
R532 KAMAYA N/A Chip Res, 1005 J 10KW
R533 KAMAYA N/A Chip Res, 1005 J 10KW
R534 KAMAYA N/A Chip Res, 1005 J 10KW
R535 KAMAYA N/A Chip Res, 1005 J 10KW
R536 KAMAYA N/A Chip Res, 1005 J 330KW
R537 KAMAYA N/A Chip Res, 1005 J 1KW
R538 KAMAYA N/A Chip Res, 1005 J 6.8KW
R539 KAMAYA N/A Chip Res, 1005 J 330KW
R540 KAMAYA N/A Chip Res, 1005 J 47KW
R541 KAMAYA N/A Chip Res, 1005 J 330KW
R609 KAMAYA N/A Chip Res, 1005 J 1KW
R610 KAMAYA N/A Chip Res, 1005 J 2.2W
R613 KAMAYA N/A Chip Res, 1005 J 15KW
R614 KAMAYA N/A Chip Res, 1005 J 390KW
R615 KAMAYA N/A Chip Res, 1005 J 2.2W
R616 KAMAYA N/A Chip Res, 1005 J 0W
R619 KAMAYA N/A Chip Res, 1005 J 10KW
R620 KAMAYA N/A Chip Res, 1005 J 33KW
R621 KAMAYA N/A Chip Res, 1005 J 39KW
R622 KAMAYA N/A Chip Res, 1005 J 0W
R623 KAMAYA N/A Chip Res, 1005 J 560W
R701 KAMAYA N/A Chip Res, 1005 J 56W
R702 KAMAYA N/A Chip Res, 1005 J 1.5KW
R703 KAMAYA N/A Chip Res, 1005 F 4.7KW
R704 KAMAYA N/A Chip Res, 1005 F 4.7KW
R705 KAMAYA N/A Chip Res, 1005 J 220W
R706 KAMAYA N/A Chip Res, 1005 J 100W
Circuit
Ref.
Supplier Supplier Part No. Description
R707 KAMAYA N/A Chip Res, 1005 J 1.5KW
R708 KAMAYA N/A Chip Res, 1005 F 4.7KW
R709 KAMAYA N/A Chip Res, 1005 F 6.8KW
R710 KAMAYA N/A Chip Res, 1005 J 220W
R711 KAMAYA N/A Chip Res, 1005 J 100KW
R712 KAMAYA N/A Chip Res, 1005 J 100KW
R713 KAMAYA N/A Chip Res, 1005 J 30KW
R714 KAMAYA N/A Chip Res, 1005 J 56W
R715 KAMAYA N/A Chip Res, 1005 J 56W
R716 KAMAYA N/A Chip Res, 1005 J 330W
R717 KAMAYA N/A Chip Res, 1005 J 10W
R718 KAMAYA N/A Chip Res, 1005 J 7.5KW
R719 KAMAYA N/A Chip Res, 1005 J 1KW
R720 KAMAYA N/A Chip Res, 1005 J 150W
R721 KAMAYA N/A Chip Res, 1005 J 150W
R722 KAMAYA N/A Chip Res, 1005 J 10KW
R723 KAMAYA N/A Chip Res, 1005 J 1KW
R724 KAMAYA N/A Chip Res, 1005 J 390W
R725 KAMAYA N/A Chip Res, 1005 J 100W
R726 KAMAYA N/A Chip Res, 1005 J 3KW
R727 KAMAYA N/A Chip Res, 1005 J 2.7KW
R728 KAMAYA N/A Chip Res, 1005 J 2.7KW
R729 KAMAYA N/A Chip Res, 1005 J 100KW
R730 KAMAYA N/A Chip Res, 1005 J 33KW
R731 KAMAYA N/A Chip Res, 1005 J 10W
R732 KAMAYA N/A Chip Res, 1005 J 10KW
R733 KAMAYA N/A Chip Res, 1005 J 0W
R734 KAMAYA N/A Chip Res, 1005 J 10W
R735 KAMAYA N/A Chip Res, 1005 J 1KW
R736 KAMAYA N/A Chip Res, 1005 J 1KW
R737 KAMAYA N/A Chip Res, 1005 J 1KW
R740 KAMAYA N/A Chip Res, 1005 J 1.5KW
