Motorola GM300

Parts List
HLE8230A RF Board, 403-433 MHz, 12.5 kHz (N)
HLE8229A RF Board, 403-433 MHz, 25 kHz (W) PL-921021-O
REFERENCE MOTOROLA
SYMBOL PART NO. DESCRIPTION
HLE8230A RF Board, 403-433 MHz, 12.5 kHz (N)
HLE8229A RF Board, 403-433 MHz, 25 kHz (W) PL-921021-O
REFERENCE MOTOROLA
SYMBOL PART NO. DESCRIPTION
capacitor, chip: +/-5%; 5 V:
unless otherwise stated
C1, 2 21-13740G27 8.2 ± 0.1 pF
C3 21-13740G17 3.9 ±0 .1 pF
C4 21-13740G30 11 pF 2%
C5 21-13740G21 5.6 ±0 .1 pF
C6 21-13740G19 4.7 ± 0.1 pF
C7 21-13740G27 8.2 ± 0.1 pF
C8 21-13740G17 3.9 ± 0.1 pF
C9 21-13740G21 5.6 ± 0.1 pF
C10 21-13740G27 8.2 ± 0.1 pF
C11 21-13740G32 13 pF 2%
C12 21-13740B45 68 pF
C13 21-13740G27 8.2 ± 0.1 pF
C14 not used
C15 21-13740G13 2.7 ± 0.1 pF
C16 21-13740G20 5.1 ± 0.1 pF
C17 21-13740G37 22 pF 2%
C18 21-13740G19 4.7 ± 0.1 pF
C19 21-13740G16 3.6 ± 0.1 pF
C20 21-13740G36 20 pF 2%
C21 21-13740G18 4.3 ± 0.1 pF
C22 21-13740G17 3.9 ± 0.1 pF
C23 21-13740G35 18 pF 2%
C24 21-13740G20 5.1 ± 0.1 pF
C25 21-13740G29 10 pF 2%
C26 21-13740G31 12 pF 2%
C27 21-11032B15 0.22 uF +80/-20%
C28 21-13740B45 68 pF
C29 not used
C30 21-13740B35 27 pF
C33 21-13741B45 .01 uF
C51 21-13740B55 180 pF
C52 21-13740B27 12 pF
C53 21-13740B47 82 pF
C54 21-13740B61 330 pF
C55, 56 21-13741B45 .01 uF
C57(N) 21-13740B29 15 pF
C57(W) 21-13740B31 18 pF
C58(N) 21-13740B25 10 pF
C58(W) 21-13740B27 12 pF
C59(N) 21-13740B29 15 pF
C59(W) 21-13740B31 18 pF
C60, 61 21-13741B45 .01 uF
C65 21-11032B15 0.22 uF +80/-20%
C66 21-13741B45 .01 uF
C67 23-13749C39 tantalum 10 uF 10% 20V
C68 21-13740B29 15 pF
C69 21-13740B39 39 pF
C70 21-13740B29 15 pF
C71, 72 21-11032B15 0.22 uF +80/-20%
C73 23-13749C39 tantalum 10 uF 10% 20V
C74 23-11048B13 lytic 10 uF 20% 16V
C75 21-13741B69 0.1 uF
C76 23-11048B05 lytic 1 uF 20% 50V
C77, 78 21-11032B15 0.22 uF +80/-20%
C79 21-13741B29 .0022 uF
C80 21-11032B15 0.22 uF +80/-20%
C81 21-13740B55 180 pF
C82, 83 21-11032B15 0.22 uF +80/-20%
C84 21-13740B09 2.2 ± .25 pF
C85 21-13740B25 10 pF
C86, 87 21-11032B15 0.22 uF +80/-20%
C90 21-13741B45 .01 uF
C91 21-13740B49 100 pF
C101 23-11048B13 lytic 10 uF 20% 16V
C102 08-11051A13 poly 0.1 uF 63V
C103 21-11032B15 0.22 uF +80/-20%
C104 21-13741B45 .01 uF
C105 23-11048B13 lytic 10 uF 20% 16V
C106 21-13740B29 15 pF
C107, 108 21-13741B69 0.1 uF
C109 08-11051A13 poly 0.1 uF 63V
C110 08-11051A19 poly 1 uF 63V
C111 08-11051A09 poly .022 uF 63V
C112 08-11051A01 poly .001 uF 63V
C113 21-13741B45 .01 uF
C114 21-13740B45 68 pF
C115 21-13741B45 .01 uF
C116 21-13740B49 100 pF
C117, 118 not used
C119, 120 21-13740B45 68 pF
C121 21-13740B19 5.6 ± .25 pF
C122 21-13740B49 100 pF
C123 21-13740B45 68 pF
C124 21-13740B25 10 pF
C125 21-13740B73 1000 pF
C126 not used
C127 thru 132 21-11032B15 0.22 uF +80/-20%
C133 21-13740B49 100 pF
C151 21-13740B73 1000 pF
C152 21-13740B47 82 pF
C153 21-13740B25 10 pF
C154 21-13741B45 .01 uF
C155, 156 21-13740B55 180 pF
C157 not used
C158 08-11051A15 poly 0.22 uF 63V
C159 21-13740B35 27 pF
C160 21-13740B29 15 pF
C161 21-13740B73 1000 pF
C162 23-11048B13 lytic 10 uF 20% 16V
C163 08-11051A17 poly 0.47 uF 63V
C164 21-11032B15 0.22 uF +80/-20%
C165 21-13741B33 .0033 uF
C176 21-13740B73 1000 pF
C201 23-11048B13 lytic 10 uF 20% 16V
C205 21-13740B49 100 pF
C206 21-13740B16 4.3 ±0 .25 pF
C207 21-13740B19 5.6 ±0 .25 pF
C208 21-13740B14 3.6 ±0 .25 pF
C209 21-13740B14 3.6 ±0 .25 pF
C210 21-13740B49 100 pF
C212 21-13740B49 100 pF
C213 21-13740B01 1 ±0 .25 pF
C214 21-13740B13 3.3 ±0 .25 pF
C215 21-13740B49 100 pF
C216 21-13740B13 3.3 ±0 .25 pF
C218 21-13740B49 100 pF
C220 21-13740B25 10 pF
C221 21-13740B05 1.5 ±0 .25 pF
C222 21-13740B49 100 pF
C224, 225 21-13740B49 100 pF
C228 21-13741B29 .0022 uF
C230, 231 21-13740B05 1.5 ±0 .25 pF
C233 21-13740B18 5.1 ±0 .25 pF
C234 21-13740B23 8.2 ±0 .25 pF
C235 21-13740B22 7.5 ±0 .25 pF
C236 21-13740B22 7.5 ±0 .25 pF
C237 21-13740B49 100 pF
C239 21-13740B49 100 pF
C240 21-13740B05 1.5 ±0 .25 pF
C242 21-13740B49 100 pF
C243 21-13740B13 3.3 ±0 .25 pF
C244 21-11032B15 0.22 uF +80/-20%
C245 21-13740B45 68 pF
C247 21-13740B23 8.2 ±0 .25 pF
C248 21-13740B01 1 ±0 .25 pF
C249 21-13740B49 100 pF
C251 21-13740B45 68 pF
C252 21-13740B49 100 pF
C253 21-13740B45 68 pF
C255 not used
C256 21-13741B45 .01 uF
C257 not used
C258 08-11051A07 poly .01 uF 63V
C259 21-13740B23 8.2 ±0 .25 pF
C260 not used
C261 21-13741B45 .01 uF
C262 not used
C263 21-13740B19 5.6 ± .25 pF
C264 not used
C265 not used
C266 21-13740B03 1.2 ±0 .25 pF
C267 21-13740B01 1 ±0 .25 pF
C268 21-13740B13 3.3 ±0 .25 pF
C269 21-13740B09 2.2 ±0 .25 pF
C270, 271 not used
C272 21-13740B45 68 pF
C273 not used
C274 21-13740B49 100 pF
C275, 276 21-13741B45 .01 uF
C277, 278 23-11048B19 lytic 47 uF 20% 16V
C279 21-13740B45 68 pF
C280 21-11032B15 0.22 uF +80/-20%
C301 21-13741B45 .01 uF
C302, thru 313 21-13740B45 68 pF
