Motorola GM338 - Page 138

3-24 Controller T7/T9 Schematic Diagrams
C0681 2113743E20 10uF D0101 4813825A05 DIODE
D0151 4813833C02 DIODE, DUAL 70V
D0179 4813833C02 DIODE, DUAL 70V
D0301 4802245J47 DIODE, SCHOTTKY
D0621 4813833C02 DIODE, DUAL 70V
D0651 4813833C02 DIODE, DUAL 70V
D0660 4813833C02 DIODE, DUAL 70V
D0661 4813833C02 DIODE, DUAL 70V
E0271 2484657R01 Ferrite Bead
E0272 2484657R01 Ferrite Bead
E0631 2484657R01 Ferrite Bead
F0401 6580542Z01 FUSE 3A
J0401 0902636Y02 12 POS. FLEX CONN
J0451 0902636Y01 CONN, FLEX, SIDE
ENTRY
J0501 0986105B01 CONN, SMD, 20 Pin
J0551 0905505Y04 CONN ZIF HORIZONTAL
J0552 0905505Y03 CONN ZIF HORIZONTAL
J0601 0986165B01 MOBILE DC PWR CONN
Q0110 4880048M01 NPN
Q0151 4880048M01 NPN
Q0171 4880048M01 NPN
Q0173 4880052M01 NPN DARLINGTON
Q0177 4880048M01 NPN
Q0181 4880048M01 NPN
Q0183 4880048M01 NPN
Q0185 4880048M01 NPN
Q0271 4880214G02 NPN
Q0641 4880048M01 NPN
Q0661 4805921T02 TRANSISTOR DUAL DIGI-
TAL NPN/PNP
Q0662 4880214G02 NPN
Circuit
Ref
Motorola
Part No
Description
Q0663 4880048M01 NPN
Q0681 4880052M01 NPN DARLINGTON
R0101 0662057A73 10K Ohm
R0102 0662057A65 4700 Ohm
R0103 0662057B47 0 Ohm
R0104 0662057A73 10K Ohm
R0106 0662057B47 0 Ohm
R0108 0662057A57 2200 Ohm
R0111 0662057B47 0 Ohm
R0113 0662057A73 10K Ohm
R0114 0662057A73 10K Ohm
R0115 0662057A73 10K Ohm
R0117 0662057A63 3900 Ohm
R0121 0662057A97 100K Ohm
R0131 0662057B46 10M Ohm
R0132 0662057B10 330K Ohm
R0151 0662057A82 24K Ohm
R0152 0662057A82 24K Ohm
R0170 0662057A73 10K Ohm
R0171 0662057A65 4700 Ohm
R0172 0662057A73 10K Ohm
R0173 0662057A65 4700 Ohm
R0174 0662057A73 10K Ohm
R0175 0662057A73 10K Ohm
R0176 0662057A84 30K Ohm
R0177 0662057A65 4700 Ohm
R0178 0662057A89 47K Ohm
R0179 0662057A89 47K Ohm
R0181 0662057A65 4700 Ohm
R0182 0662057A89 47K Ohm
R0183 0662057A65 4700 Ohm
R0184 0662057A89 47K Ohm
Circuit
Ref
Motorola
Part No
Description
R0185 0662057A65 4700 Ohm
R0186 0662057A89 47K Ohm
R0201 0662057A25 100 Ohm
R0202 0662057A43 560 Ohm
R0203 0662057A25 100 Ohm
R0204 0662057A43 560 Ohm
R0205 0662057A73 10K Ohm
R0206 0662057A73 10K Ohm
R0207 0662057A57 2200 Ohm
R0208 0662057A57 2200 Ohm
R0211 0660076E70 7500 Ohm
R0212 0660076E70 7500 Ohm
R0221 0662057A82 24K Ohm
R0222 0662057A82 24K Ohm
R0223 0662057A84 30K Ohm
R0224 0662057A71 8200 Ohm
R0228 0662057B47 0 Ohm
R0229 0662057A01 10 Ohm
R0241 0662057A89 47K Ohm
R0242 0662057B47 0 Ohm
R0251 0662057A89 47K Ohm
R0252 0662057A91 56K Ohm
R0253 0662057A97 100K Ohm
R0254 0662057A73 10K Ohm
R0255 0662057A73 10K Ohm
R0256 0662057A97 100K Ohm
R0257 0662057A57 2200 Ohm
R0261 0662057A73 10K Ohm
R0262 0662057A97 100K Ohm
R0265 0662057A82 24K Ohm
R0267 0662057A89 47K Ohm
R0268 0662057A73 10K Ohm
Circuit
Ref
Motorola
Part No
Description
R0269 0662057A41 470 Ohm
R0273 0662057A82 24K Ohm
R0275 0662057A73 10K Ohm
R0276 0662057A77 15K Ohm
R0323 0662057A79 18K Ohm
R0324 0662057A79 18K Ohm
R0331 0662057A73 10K Ohm
R0332 0662057A73 10K Ohm
R0333 0662057A73 10K Ohm
R0335 0662057B02 150K Ohm
R0341 0662057A73 10K Ohm
R0342 0662057A55 1800 Ohm
R0343 0662057B47 0 Ohm
R0344 0662057A91 56K Ohm
R0345 0662057A66 5100 Ohm
R0346 0662057A89 47K Ohm
R0347 0662057A89 47K Ohm
R0401 0662057A33 220 Ohm
R0407 0662057M26 10 Ohm
R0408 0662057A25 100 Ohm
R0409 0662057M26 10 Ohm
R0412 0662057B47 0 Ohm
R0441 0662057B47 0 Ohm
R0442 0662057A49 1000 Ohm
R0467 0662057M26 10 Ohm
R0468 0662057A97 100K Ohm
R0481 0662057B47 0 Ohm
R0482 0662057B47 0 Ohm
R0510 0662057A65 4700 Ohm
R0511 0662057A97 100K Ohm
R0512 0662057A77 15K Ohm
R0525 0662057A97 100K Ohm
Circuit
Ref
Motorola
Part No
Description
