4-14 UHF PCB 8480450Z03 / PCB 8480587Z01 Parts List
C343 2113743A23 0.22uF
C344 2113743M24 0.1uF
C345 2113743M24 0.1uF
C346 2113743M24 0.1uF
C347 2113743M24 0.1uF
C348 2113743M24 0.1uF
C349 2113743E07 .022uF
C350 2113743L05 330pF
C351 2113743N33 20pF
C352 2113743N28 12pF
C353 2113743N41 43pF
C354 2113743N42 47pF
C355 2113743A21 0.15uF
C356 2113743M08 .022uF
C357 2113743A23 0.22uF,
C358 2113741A23 1200pF
C359 2109720D14 0.1uF
C360 2113743E07 .022uF
C361 2113741F49 0.1uF
C362 2113928N01 0.5pF
C363 2311049A07 1uF
C364 2113743L39 8200 pF
C370 2113743N50 100pF
C371 Not Placed
C372 Not Placed
C373 Not Placed
C374 2113743N50 100pF
C375 2113743N50 100pF
C378 Not Placed
C380 2113743L41 .01uF, 10%
C381 2113743N25 9.1pF, 0.5
C382 2311049A59 10uF, 10%; 6V
C383 2113743N50 100pF
C384 2113743N44 56pF
C385 2113743N44 56pF
C386 2113743N50 100pF
C390 2113743N50 100pF
C391 Not Placed
C395 2113743N50 100pF
C396 Not Placed
C397 2311049A07 1uF, 10%; 16V
Circuit
Ref
Motorola
Part No.
Description
C400 2113743L41 .01uF, 10%
C401 2113743M24 0.1uF
C402 2113743M24 0.1uF
C403 2113928D08 10uF
C407 2113928N01 0.1uF
C408 2113743N50 100pF
C409 2113743M24 0.1uF
C410 2113928N01 0.1uF
C411 2113743M24 0.1uF
C414 2113743M24 0.1uF
C415 2109720D01 .01uF
C416 2113928N01 0.1uF
C419 Not Placed
C420 2113743L41 .01uF
C421 2113928N01 0.1uF
C422 2113743M24 0.1uF
C423 2113743N50 100pF
C424 2311049A59 10uF
C425 2113743M24 0.1uF
C426 2113743N50 100pF
C427 2113743N50 100pF
C428 2113743M24 0.1uF
C429 2113743M24 0.1uF
C430 2113928N01 0.1uF
C431 2113743N50 100pF
C432 Not Placed
C433 2113743L41 .01uF
C434 2113743M24 0.1uF (not placed non-display
radios)
C435 2113743M24 0.1uF
C436 2113743N34 22pF (not placed non-display
radios)
C437 2113743N34 22pF (not placed non-display
radios)
C440 2113743G26 4.7uF
C441 2113743N50 100pF
C442 2113743E20 0.1uF
C443 2113928N01 0.1uF
C444 2113743N50 100pF
C445 2113743N50 100pF
C447 2113928N01 0.1uF, 10%
Circuit
Ref
Motorola
Part No.
Description
C448 2113928N01 0.1uF, 10%
C449 2113743N50 100pF
C450 2113743M24 0.1uF, +80%/-20%
C451 2113743M08 .022uF, +80%/-20%
C452 2113743G26 4.7uF, +80%/-20%
C453 2113743N50 100pF
C456 2113743N50 100pF
C458 2113743N50 100pF
C459 2113743N50 100pF
C463 2113743N50 100pF
C466 2113743N50 100pF
C467 2113928N01 0.1uF, 10%
C471 2113743N50 100pF
C472 2113743N50 100pF
C473 2113743N50 100pF
C475 2113743H14 10uF
C476 2113928D08 10uF
C479 2113928N01 0.1uF
C480 2113928D08 10uF
C481 2113928N01 0.1uF
C482 2113928N01 0.1uF
C490 -
C497 2113743N50 100pF
C502 2311049A05 0.47uF
C503 2113743N50 100pF
C505 2113743N50 100pF
C511 2113743N50 100pF
C512 2113743N50 100pF
C513 2113743N50 100pF
C514 2113743N50 100pF
C520 2113743L41 .01uF, 10%
C521 2113743L41 .01uF, 10%
C522 2113743L41 .01uF, 10%
C523 2113743L41 .01uF, 10%
CR101 4880973Z02 Pin Diode
CR102 4802245J41 Pin Diode
CR105 5185963A15 Temperature Sense
CR201 4802233J09 Triple Diode
CR203 4862824C03 Varactor
CR241 4805649Q13 Dual Varactor
CR242 4862824C01 Varactor
Circuit
Ref
Motorola
Part No.
Description
CR243 4862824C01 Va rac tor
CR251 4802245J22 Varactor
CR301 4862824C01 Va rac tor
CR302 4862824C01 Varactor
CR303 4880154K03 Dual Comm Anode-Cathode
CR304 4862824C01 Varactor
CR305 4862824C01 Va rac tor
CR306 4802245J42 Ring Quad Diode
CR308 4802245J41 Pin Diode
CR310 4862824C01 Varactor
CR411 4802245J47 Schottky Diode
CR412 4802245J47 Schottky Diode
CR413 4802245J47 Schottky Diode
CR440 4813833C02 Dual Diode Common Cathode
CR501 4880107R01 Rectifier
CR503 4805729G49 LED Red/Yel
E101 2484657R01 Ferrite Bead
E400 -
E409 2480640Z01 Ferrite Bead
F501 6580542Z01 Fuse 3A
FL201 - 16.8MHz Xtal (Clip)
FL301 4802245J43 Xtal Filter 45.1MHz
FL401 4870368G02 Osc Xtal 38.4kHz (not placed
non-display radios)
H101 2680499Z01 Heat Spreader
J101 0180117S05 RF Jack Assembly
J102 0280519Z02 Antenna Nut
J400 0905505Y04 40-pins Connector
J403 0905505Y02 20-pins Connector
L101 2460591B80 19.61nH
L102 2460591B80 19.61nH
L104 2460591B80 19.61nH
L105 2462587N22 390nH
L106 2460591A11 7.66nH
L107 2460591G24 33.47nH
L108 2460591A01 4.22nH
L109 2460591B04 11.03nH
L112 2462587N22 390nH
L113 2413926H09 5.6nH
L114 2462587N22 390nH
L115 2462587N22 390nH
Circuit
Ref
Motorola
Part No.
Description
