Motorola GP series

UHF PCB 8480450Z03 / PCB 8480587Z01 Parts List 4-15
L116 2460591A50 9.75nH
L160 2413926H14 15.0nH
L201 2462587Q20 2.2uH
L202 2462587Q20 2.2uH
L203 2462587Q20 2.2uH
L232 2462587P25 12uH
L241 2462587V41 390nH
L242 2462587V38 220nH
L243 2460593C01 Teflon Resonator
L251 2462587V28 33nH
L253 2460593C02 Teflon Resonator
L261 2462587V29 39nH
L271 2462587V32 68nH
L273 2462587V28 33nH
L281 2462587V41 390nH
L282 2462587V41 390nH
L301 2460591C04 13.9nH
L302 2460591C04 13.9nH
L303 2462587V38 220nH
L304 2462587V37 180nH
L305 2462587V27 27nH
L306 2460591C04 13.9nH
L307 2460591C04 13.9nH
L309 2460591C16 16.28nH
L310 2462587V36 150nH
L311 2462587N65 750nH
L314 2462587N72 2.2uH
L321 Not Placed
L325 2480646Z20 2.2uH
L330 2462587N64 680nH
L331 2480646Z20 2.2uH
L332 2462587N53 100nH
L340 2462587V41 390nH
L400 2462587Q42 390nH
L401 2462587Q42 390nH
L410 2462587Q42 390nH
L411 2462587Q42 390nH
L505 2462587Q42 390nH
P100 3905643V01 Gnd Contact Finger
PB501 4080523Z01 Tactile, Pushbutton
PB502 4080523Z01 Tactile, Pushbutton
Circuit
Ref
Motorola
Part No.
Description
PB503 4080523Z01 Tactile, Pushbutton
PB504 4080523Z01 Tactile, Pushbutton
PB505 4080523Z01 Tactile, Pushbutton
Q110 4802245J55 RF Power FET
Q111 4802245J50 Dual NPN/PNP
Q210 4802245J50 Dual NPN/PNP
Q241 4805218N63 NPN
Q260 4802245J50 Dual NPN/PNP
Q261 4802245J50 Dual NPN/PNP
Q301 4802245J44 NPN
Q302 4802245J44 NPN
Q310 Not Placed
Q315 4880214G02 NPN
Q316 Not Placed
Q320 4805218N63 NPN
Q400 4809579E18 MOSFET P-Chan
Q403 4880214G02 NPN
Q405 4802245J54 Dual NPN
Q410 4802245J54 Dual NPN
Q416 4809579E18 MOSFET P-Chan (not placed
non-display radios)
Q417 4802245J50 Dual NPN/PNP
Q502 5180159R01 Dual NPN
Q505 4880214G02 NPN
R101 0662057A34 240
R102 0680539Z01 0.1
R103 0662057M41 43
R104 0662057M81 2K
R106 0662057M26 10
R107 Not Placed
R108 Not Placed
R109 0662057N30 200K
R110 0662057M61 300
R111 0662057M33 20
R112 0662057M61 300
R120 0662057M01 0
R130 0662057M98 10K
R131 0662057M98 10K
R132 0662057N39 470K
R133 Not Placed
R161 0662057M57 200
Circuit
Ref
Motorola
Part No.
Description
R170 0662057A34 240
R171 0662057M92 5.6K
R172 0662057A32 200
R173 0662057N47 1MEG
R201 0662057N21 82K
R202 0662057N23 100K
R204 0662057N15 47K
R231 0662057M52 120
R232 0662057M69 620
R233 0662057M68 560
R241 0662057M32 18
R242 0662057M57 200
R243 0662057M98 10K
R244 0662057N01 12K
R245 0662057M59 240
R248 0662057M37 30
R251 0662057M32 18
R252 0662057M62 330
R253 0662057M95 7.5K
R254 0662057M95 7.5K
R255 0662057M89 4.3K
R256 0662057M37 30
R260 0662057M74 1K
R281 0662057M01 0
R300 0662057M82 2.2K
R301 0662057N23 100K
R302 0662057N23 100K
R303 0662057M74 1K
R304 0662057N01 12K
R305 0662057M67 510
R306 0662057N23 100K
R307 0662057N23 100K
R308 0662057M60 270
R309 0662057M32 18
R310 0662057M60 270
R311 0662057N10 30K
R312 0662057M83 2.4K
R313 0662057M62 330
R314 0662057M85 3K
R315 0662057N01 12K
R316 0662057A96 36K
Circuit
Ref
Motorola
Part No.
Description
R317 0662057M74 1K
R318 0662057A79 18K
R319 0662057A29 150
R320 0662057M88 3.9K
R321 0662057M74 1K
R322 0662057N30 200K
R324 0662057M81 2K
R325 0662057M94 6.8K
R326 Not Placed
R327 0662057N11 33K
R328 0662057M12 2.7
R329 0662057M01 0
R330 Not Placed
R331 Not Placed
R332 Not Placed
R333 Not Placed
R334 Not Placed
R335 Not Placed
R336 Not Placed
R338 Not Placed
R339 0662057M01 0
R340 0662057M94 6.8K
R342 0662057N23 100K
R343 0662057M26 10
R344 0662057N01 12K
R345 0662057M98 10K
R346 0662057N17 56K
R347 0662057M74 1K
R348 0662057M87 3.6K
R349 0662057C01 0
R350 0662057N23 100K
R351 0662057C01 0
R352 0662057M86 3.3K
R355 0662057M01 0
R400 0662057N15 47K
R401 0662057M01 0
R402 Not Placed
R403 Not Placed
R405 0662057M01 0
R406 0662057N20 75K
R407 0662057N19 68K
Circuit
Ref
Motorola
Part No.
Description
