Motorola GP series Service Manual

4-12 800MHz PCB 8480641Z03 Parts List
C421 2113928N01 Capacitor Chip 0.1µF
C422 2113743M24 Capacitor Chip 0.1µF
C423 2113743N46 Capacitor Chip 68pF
C424 2311049A59 Capacitor Tantalum 10µF
C425 2113743M24 Capacitor Chip 0.1µF
C426 2113743N46 Capacitor Chip 68pF
C427 2113743N46 Capacitor Chip 68pF
C428 2113743M24 Capacitor Chip 0.1µF
C429 2113743M24 Capacitor Chip 0.1µF
C430 2113928N01 Capacitor Chip 0.1µF
C431 2113743N46 Capacitor Chip 68pF
C433 2113743L41 Capacitor Chip .01µF
C434 2113743M24 Capacitor Chip 0.1µF
C435 2113743M24 Capacitor Chip 0.1µF
C436 2113743N34 Capacitor Chip 22pF
C437 2113743N34 Capacitor Chip 22pF
C438 2113743F18 Capacitor Chip 2.2µF
C439 2113743L17 Capacitor Chip 1000pF
C440 2113743F18 Capacitor Chip 2.2µF
C441 2113743N46 Capacitor Chip 68pF
C442 2113743E20 Capacitor Chip 0.1µF
C443 2113928N01 Capacitor Chip 0.1µF
C444 2113743N46 Capacitor Chip 68pF
C445 2113743N46 Capacitor Chip 68pF
C447 2113743M08 Capacitor Chip .022µF
C448 2113928N01 Capacitor Chip 0.1µF
C449 2113743N46 Capacitor Chip 68pF
C451 2113743M08 Capacitor Chip .022µF
C452 2113743B29 Capacitor Chip 1µF
C453 2113743N46 Capacitor Chip 68pF
C456 2113743N46 Capacitor Chip 68pF
C458 2113743N46 Capacitor Chip 68pF
C459 2113743N46 Capacitor Chip 68pF
C463 2113743N46 Capacitor Chip 68pF
C466 2113743N46 Capacitor Chip 68pF
C467 2113928N01 Capacitor Chip 0.1µF
C471 to
C473
2113743N46 Capacitor Chip 68pF
C475 2113743H14 Capacitor Chip 10µF
C476 2113928D08 Capacitor Chip 10µF
C479 2113928N01 Capacitor Chip 0.1µF
C480 2113743G26 Capacitor Chip 4.7µF
C481 2113928N01 Capacitor Chip 0.1µF
C482 2113928N01 Capacitor Chip 0.1µF
C490 to
C497
2113743N46 Capacitor Chip 68pF
C502 2311049A05 Capacitor Tantalum 0.47µF
C503 2113743N46 Capacitor Chip 68pF
C505 2113743N46 Capacitor Chip 68pF
C511 to
C514
2113743N46 Capacitor Chip 68pF
Circuit
Ref
Motorola
Part No.
Description
C520 to
C523
2113743L41 Capacitor Chip .01µF
C524 2113743N32 Capacitor Chip 18pF
C525 to
C529
2113743N48 Capacitor Chip 82pF
C530 2311049A18 Capacitor Tantalum 10µF
C531 2113743N48 Capacitor Chip 82pF
CR101 4880973Z02 Diode PIN MA4PH261
CR102 4880973Z02 Diode PIN MA4PH261
CR251
to
CR253
4862824C01 Diode Varactor 1SV229
CR300 4880154K03 Diode Schottky MMBD353LT1
CR301 4802245J41 Diode Switching HSMP3820
CR350 4862824C01 Diode Varactor 1SV229
CR411 to
CR413
4802245J62 Diode Array RB731U
CR440 4813833C02 Diode Dual Common Cath-
ode MMBD6100LT1
CR501 4880107R01 Diode Rectifier BYD17D
CR503 4805729G49 Opto-Device LED
BRPY1204W
D201 4802233J09 Diode Array IMN10
D202 4802233J09 Diode Array IMN10
E101 2484657R01 2743019447
(for PCB No. 8480641Z03
Rev B only)
E102 2405688Z01 2744044446
E400 to
E409
2480640Z01 BK1005HM471
F501 6580542Z01 Protector 1608FF
FL300 9180657Z01 Filter
FL301 9180657Z01 Filter
FL350 4885631B01 Filter 31B01
FL401 4870368G02 Oscillator Crystal 68G02
J101 2880658Z02 Connector
J400 0905505Y04 Connector Multi_pin
FH12-40S-0.5SH
J403 0905505Y02 Connector Multi_pin CL586-
0524-9
L101 2460591A29 Inductor Airwound 6.61nH
L102 2460591A29 Inductor Airwound 6.61nH
L103 2460591A49 Inductor Airwound 8.01nH
L104 2462587V38 Inductor 220nH
L106 2479990B02 Inductor Airwound 19.61nH
L107 2413926G05 Inductor 6.8nH
L108 2413926G09 Inductor 15nH
L109 2462587V38 Inductor 220nH
L110 2413926G04 Inductor 5.6nH
L111 2413926G06 Inductor 8.2nH
L112 2479990A01 Inductor Airwound 4.22nH
Circuit
Ref
Motorola
Part No.
Description
L113 2462587V27 Inductor 27nH
L200 2462587Q20 Inductor 2.2µH
L202 2462587Q20 Inductor 2.2µH
L203 2462587V21 Inductor 6.8nH
L204 2462587P25 Inductor 12µH
L250 2462587V21 Inductor 6.8nH
L252 2462587V38 Inductor 220nH
L253 2462587V41 Inductor 390nH
L254 2462587V28 Inductor 33nH
L256 to
L260
2462587V38 Inductor 220nH
L261 2462587V26 Inductor 22nH
L262 2462587V38 Inductor 220nH
L263 2462587V25 Inductor 18nH
L264 2462587V24 Inductor 15nH
L265 2462587V30 Inductor 47nH
L301 2462587V20 Inductor 3.3nH
L302 2462587V38 Inductor 220nH
L303 2462587V41 Inductor 390nH
L304 2413926G08 Inductor 12nH
L306 2462587V32 Inductor 68nH
L307 2462587V26 Inductor 22nH
L308 2462587V30 Inductor 47nH
L309 2462587V38 Inductor 220nH
L310 2462587V22 Inductor 8.2nH
L350 2462587Q20 Inductor 2.2µH
L351 2462587T22 Inductor 390nH
L352 2462587T22 Inductor 390nH
L353 2462587V35 Inductor 120nH
L354 2462587T23 Inductor 470nH
L355 2462587V38 Inductor 220nH
L356 2462587T40 Inductor 33nH
L357 2462587Q20 Inductor 2.2µH
L400 2462587Q42 Inductor 390nH
L401 2462587Q42 Inductor 390nH
L410 2462587Q42 Inductor 390nH
L411 2462587Q42 Inductor 390nH
L505 2462587Q42 Inductor 390nH
PB501 to
PB505
4080523Z01 Mechanical KSS223G
Q101 5105385Y73 Transistor 85Y73
Q200 4802245J50 Transistor Bipolar
Q210 4802245J50 Transistor Bipolar
Q251 4805218N63 Transistor Bipolar BFQ67W
Q252 4802245J50 Transistor Bipolar
Q302 4802245J56 Transistor Bipolar QSBT0048
Q304 4802245J44 Transistor Bipolar HP415
Q350 4805218N63 Transistor Bipolar BFQ67W
Q400 4809579E18 Transistor FET TP0101T
Q403 4880214G02 Transistor Bipolar
MMBT3904L
Circuit
Ref
Motorola
Part No.
Description
Q405 4802245J54 Transistor Bipolar UMG5N
Q410 4802245J54 Transistor Bipolar UMG5N
Q416 4809579E18 Transistor FET TP0101T
Q417 4802245J50 Transistor Bipolar
Q502 5180159R01 Transistor Bipolar IMX1
Q505 4880214G02 Transistor Bipolar
MMBT3904L
R101 0662057A34 Resistor Chip 240
R102 0662057A34 Resistor Chip 240
R103 0662057A18 Resistor Chip 51
R104 0680539Z01 Resistor Chip 0.1
R105 0662057M81 Resistor Chip 2K
R106 0662057M01 Resistor Chip 0
R107 0662057N13 Resistor Chip 39K
R108 0662057N08 Resistor Chip 24K
R109 0662057N20 Resistor Chip 75K
R110 0662057M47 Resistor Chip 75
R111 0680195M01 Resistor Chip 10
R112 0662057M01 Resistor Chip 0
R113 0662057N30 Resistor Chip 200K
R114 0662057M67 Resistor Chip 510
R115 0662057N39 Resistor Chip 470K
R116 0662057M85 Resistor Chip 3K
R117 0662057M98 Resistor Chip 10K
R200 0662057M50 Resistor Chip 100
R202 0662057M88 Resistor Chip 3.9K
R203 0662057M38 Resistor Chip 33
R204 0662057M52 Resistor Chip 120
R206 0662057N10 Resistor Chip 30K
R208 0662057N17 Resistor Chip 56K
R209 0662057M77 Resistor Chip 1.3K
R210 0662057M62 Resistor Chip 330
R213 0662057M50 Resistor Chip 100
R214 0662057N15 Resistor Chip 47K
R216 0662057M01 Resistor Chip 0
R217 0662057M01 Resistor Chip 0
R218 0662057N11 Resistor Chip 33K
R219 0662057M54 Resistor Chip 150
R220 0662057M54 Resistor Chip 150
R222 0662057M01 Resistor Chip 0
R250 0662057M60 Resistor Chip 270
R251 0662057M50 Resistor Chip 100
R253 0662057M26 Resistor Chip 10
R254 0662057N15 Resistor Chip 47K
R255 0662057M62 Resistor Chip 330
R256 0662057M01 Resistor Chip 0
R257 0662057M74 Resistor Chip 1K
R261 0662057M38 Resistor Chip 33
R262 0662057M38 Resistor Chip 33
R263 0662057M60 Resistor Chip 270
R264 0662057M60 Resistor Chip 270
Circuit
Ref
Motorola
Part No.
Description

Motorola GP series Specifications

General

Operating Temperature	-30°C to +60°C
Frequency Range	136-174 MHz
Number of Channels	16
Channel Spacing	12.5 kHz / 25 kHz
Battery Life	8 hours (with standard battery)
Operating Voltage	7.5V DC
Ingress Protection	IP54
MIL-STD	810 C, D, E, F
