Motorola GP series Service Manual

800MHz PCB 8480641Z03 Parts List 4-13
* Motorola Depot Servicing only
Reference designators with an asterisk indicate
components which are not fieldreplaceable
because they need to be calibrated with
specialized factory equipment after installation.
Radios in which these parts have been replaced in
the field will be off frequency at temperature
extremes.
R265 0662057N10 Resistor Chip 30K
R266 0662057N10 Resistor Chip 30K
R267 0662057N01 Resistor Chip 12K
R268 0662057N07 Resistor Chip 22K
R270 to
R273
0662057M38 Resistor Chip 33
R274 0662057M52 Resistor Chip 120
R275 0662057M26 Resistor Chip 10
R306 0662057M92 Resistor Chip 5.6K
R307 0662057N17 Resistor Chip 56K
R309 0662057M70 Resistor Chip 680
R310 0662057N01 Resistor Chip 12K
R312 0662057M62 Resistor Chip 330
R315 0662057M74 Resistor Chip 1K
R317 0662057M96 Resistor Chip 8.2K
R318 0662057M72 Resistor Chip 820
R320 0662057M52 Resistor Chip 120
R321 0662057M43 Resistor Chip 51
R322 0662057M52 Resistor Chip 120
R323 0662057M87 Resistor Chip 3.6K
R324 0662057M68 Resistor Chip 560
R325 0662057N10 Resistor Chip 30K
R326 0662057M42 Resistor Chip 47
R327 0662057M40 Resistor Chip 39
R328 0662057N03 Resistor Chip 15K
R350 0662057M33 Resistor Chip 20
R351 0662057M52 Resistor Chip 120
R352 0662057N01 Resistor Chip 12K
R353 0662057N01 Resistor Chip 12K
R355 0662057M98 Resistor Chip 10K
R356 0662057M78 Resistor Chip 1.5K
R358 0662057N15 Resistor Chip 47K
R359 0662057M78 Resistor Chip 1.5K
R360 0662057N15 Resistor Chip 47K
R361 0662057M57 Resistor Chip 200
R362 0662057M98 Resistor Chip 10K
R363 0662057N15 Resistor Chip 47K
R364 0662057M81 Resistor Chip 2K
R365 0662057M87 Resistor Chip 3.6K
R366 0662057M78 Resistor Chip 1.5K
R400 0662057N15 Resistor Chip 47K
R401 0662057M01 Resistor Chip 0
R405 0662057M01 Resistor Chip 0
R406 0662057N20 Resistor Chip 75K
R407 0662057N19 Resistor Chip 68K
R409 0662057M98 Resistor Chip 10K
R410 0662057N23 Resistor Chip 100K
R411 0662057M98 Resistor Chip 10K
R413 0662057M01 Resistor Chip 0
R414 0662057V34 Resistor Chip 180K
R415 0662057V26 Resistor Chip 91K
Circuit
Ref
Motorola
Part No.
Description
R416 0662057M90 Resistor Chip 4.7K
R419 0662057M67 Resistor Chip 510
R420 0662057B46 Resistor Chip 10MEG
R421 0662057M81 Resistor Chip 2K
R423 0662057N39 Resistor Chip 470K
R424 0662057N12 Resistor Chip 36K
R425 0662057N10 Resistor Chip 30K
R426 0662057N35 Resistor Chip 330K
R427 0662057M84 Resistor Chip 2.7K
R428 0662057M10 Resistor Chip 2.2
R429 0662057M98 Resistor Chip 10K
R431 0662057N39 Resistor Chip 470K
R432 0662057N16 Resistor Chip 51K
R434 0662057M62 Resistor Chip 330
R435 0662057M81 Resistor Chip 2K
R436 0662057M74 Resistor Chip 1K
R437 0662057M01 Resistor Chip 0
R438 0662057M54 Resistor Chip 150
R439 0662057M54 Resistor Chip 150
R445 0662057N08 Resistor Chip 24K
R446 0662057N22 Resistor Chip 91K
R447 0662057N38 Resistor Chip 430K
R448 0662057N06 Resistor Chip 20K
R449 0662057N08 Resistor Chip 24K
R450 0683962T45 Resistor Chip 68
R457 0662057M98 Resistor Chip 10K
R460 0662057M90 Resistor Chip 4.7K
R461 0662057M56 Resistor Chip 180
R462 0662057M98 Resistor Chip 10K
R463 0662057M61 Resistor Chip 300
R471 0662057M92 Resistor Chip 5.6K
R472 0662057N12 Resistor Chip 36K
R473 0662057M26 Resistor Chip 10
R475 0662057M01 Resistor Chip 0
R476 0662057N08 Resistor Chip 24K
R477 0662057M74 Resistor Chip 1K
R478 0662057M98 Resistor Chip 10K
R481 0662057N08 Resistor Chip 24K
R492 0662057M01 Resistor Chip 0
R501 0662057M70 Resistor Chip 680
R502 0662057M56 Resistor Chip 180
R505 0662057M98 Resistor Chip 10K
R506 0662057N15 Resistor Chip 47K
R507 0662057M01 Resistor Chip 0
RT400 0680590Z01 Resistor Thermal 33.0K
S501 4080710Z01 Mechanical Rotary Switch
(PMUF1063 only)
S501 4080710Z02 Mechanical Rotary Switch
(PMUF1064 only)
S502 1880619Z01 Mechanical
SH100 2680507Z01 Mechanical Shield 07Z01
Circuit
Ref
Motorola
Part No.
Description
SH101 2686081B04 Mechanical Shield 81B04
SH102 2680554Z01 Mechanical Shield 54Z01
SH201 2680511Z01 Mechanical Shield 11Z01
SH202 2680511Z01 Mechanical Shield 11Z01
SH250 2680514Z01 Mechanical Shield 14Z01
SH251 2680513Z01 Mechanical Shield 13Z01
SH301 2680554Z01 Mechanical Shield 54Z01
SH303 2680508Z01 Mechanical Shield 08Z01
SH350 2680508Z01 Mechanical Shield 08Z01
SH351 2680697Z01 Mechanical Shield 97Z01
SH352 2680553Z01 Mechanical Shield 53Z01
SH353 2680514Z01 Mechanical Shield 14Z01
SH400 2680505Z01 Mechanical Shield 05Z01
SH401 2680506Z01 Mechanical Shield 06Z01
SH402 2680515Z01 Mechanical Shield 15Z01
SH403 2680516Z01 Mechanical Shield 16Z01
U101 5102463J66 Analog IC Amp RF2103P
U102 5185765B28 Custom IC H99S-4
U103 5185963A15 Analog IC LM50CIM3X
U201 5185963A27 Custom IC ASIC 63A27
U205 4802245J58 Oscillator
DRR030KER900TCT
U206 4802245J57 Oscillator
DRR030KE1R225TC
U247 5105739X05 Analog IC ADP3300
U248 5102463J58 Analog IC Voltage Regulator
LP2980AIM5
U250 5105750U54 Custom IC Buffer/Driver
50U54
U301 5185963A43 Analog IC
MA4EX900L-1226
U302 5185623B01 Digital IC Gate
TC7SU04FTE85L
U350 5185623B01 Digital IC Gate
TC7SU04FTE85L
U351 5109632D83 Custom IC 32D83
U352 4885622B01 Transistor BF904
U400 5102463J40 Analog IC Voltage Regulator
LP2951ACMM-3.3
U404 5185963A53 Custom IC 63A53
U405 5102463J36 Digital IC Memory
* U406 5102463J60 Digital IC Memory
AT49LV040-90T1
* U407 5102463J64 Digital IC Memory
X25128-2.7
U409 5102226J56 Digital IC Microprocessor
MC68HC11FL0PU1
U410 5102463J57 Analog IC Voltage Regulator
ILC7062
U420 5102463J44 Analog IC Amp TDA8547TS
Circuit
Ref
Motorola
Part No.
Description
VR432
to
VR433
4805656W08 Diode MMQA5V6T1
VR434 4802245J73 Diode Zener UDZSTE17
VR445
to
VR449
4802245J74 Diode Zener UDZSTE17
VR450 4802245J75 Diode Zener UDZSTE17
VR501 4813830A18 Diode Zener MMBZ5235BLT1
VR502 4880140L17 Diode Zener MMBZ5242B
VR503
to
VR508
4802245J73 Diode Zener UDZSTE17
Y200 4802245J68 Oscillator Crystal TTS12V
Circuit
Ref
Motorola
Part No.
Description

Motorola GP series Specifications

General

Operating Temperature	-30°C to +60°C
Frequency Range	136-174 MHz
Number of Channels	16
Channel Spacing	12.5 kHz / 25 kHz
Battery Life	8 hours (with standard battery)
Operating Voltage	7.5V DC
Ingress Protection	IP54
MIL-STD	810 C, D, E, F
