Motorola GP2000 Service Manual

2-6 Radio Disassembly Ñ Detailed
the housing or the O-ring underneath.
7. Lift rear chassis away from the front cover (see ÒFigure 2-3Ó). Be careful not to damage the
speaker wire underneath.
8. Slide the rear chassis downwards, and away from the front cover.
9. Remove the speaker connector, which connects between RF Board and the internal speaker
on front cover (see ÒFigure 2-4Ó).
Figure 2-3
Figure 2-4

Motorola GP2000 Specifications

General

Sealing	IP54
Channel Capacity	16 channels
Power Output	5W
Battery Life	8 hours
Weight	350 g
