2-14 Service Aids
9.0 Service Aids
Table 2-1 lists service aids recommended for working on the Alpha Series Radios. While all of these
items are available from Motorola, most are standard shop equipment items, and any equivalent
item capable of the same performance may be substituted for the item listed.
Table 2-1 Service Aids
Motorola
Part No.
Description Application
PMVN4059_ Customer Programming Soft-
ware - Software on 3.5Ó ßoppy
diskettes
Program customer option and channel data.
PMVN4061_ Customer Programming Soft-
ware - Software on CD Rom
Program customer option and channel data.
PMVN4060_ Tuner - Software on 3.5Ó ßoppy
diskettes
Tune hardware parameters, front end, power, etc.
PMVN4062_ Tuner - Software on CD Rom Tune hardware parameters, front end, power, etc.
DSK001C706 Programming Cable (2.5mm) Connects radio and IF Test Box to Computer.
PMKN4003A Cloning Cable (2.5mm) To clone programmable information from one radio to
another radio.
DSK001C704 Test Cable Connects radio to IF Test Box.
DSK001C714 Interconnect Service Cable Connects RF board and CPU board.
DSK001C702 IF Test Box Enables connection to the audio/accessory jack.
Allows switching for radio testing.
DSK001C705 Battery Eliminator Interconnects radio to power supply (red-and-black
power cable included).
HLN8262A BNC Adaptor Adapts radioÕs antenna port to BNC cabling of test
equipment.
ENG/DA51 Ceramic Tuning Tool To tune the variable resistor (RV601 for audio modu-
lation adjustment and RV602 for sub-audio modula-
tion adjustment).
4 mm Socket Wrench Used to remove hexagon stud from the RF board.
Phillips Head Screwdriver Used to remove M2 and M2.6 Phillips screws.
TT907A
National Ser-
vice Technical
Guide
Repairing Leadless Compo-
nent Assemblies
How to successfully remove and replace surface
mount devices.
