Motorola GP2000 Service Manual

Section 7 -18 Circuit Board/Schematic Diagrams and Parts List
VHF 136-174 MHz Radio Parts List (Controller Board)
Circuit Ref Description Vendor
Vendor Part
Number
Motorola Equivalent
Part Number
CAPACITOR
C101 47pF; 50V; +-5% Murata GRM39CH470J50PT 2113740F43
C102 10pF; 50V; +-0.5pF Murata GRM39CH100D50PT 2113740F27
C103 10pF; 50V; +-0.5pF Murata GRM39CH100D50PT 2113740F27
C104 100pF; 50V; +-5% Murata GRM39CH101J50PT 2113740F51
C105 0.1uF; 25V; +-10% Murata GRM39B104K25PT N/A
C106 33pF; 50V; +-5% Murata GRM39CH330J50PT 2113740F39
C107 0.01uF; 50V; +-10% Murata GRM39B103K50PT N/A
C108 0.1uF; 25V; +-10% Murata GRM39B104K25PT N/A
C109 0.1uF; 25V; +-10% Murata GRM39B104K25PT N/A
C110 0.001uF; 50V; +-10% Murata GRM39B102K50PT N/A
C111 47uF; 6.3V; +-20% Ni-Chemi-Con 6MCM476MB2TER N/A
C112 0.1uF; 25V; +-10% Murata GRM39B104K25PT N/A
C113 0.001uF; 50V; +-10% Murata GRM39B102K50PT N/A
C114 47uF; 6.3V; +-20% Ni-Chemi-Con 6MCM476MB2TER N/A
C115 47uF; 6.3V; +-20% Ni-Chemi-Con 6MCM476MB2TER N/A
C116 47uF; 6.3V; +-20% Ni-Chemi-Con 6MCM476MB2TER N/A
C117 1uF; 6.3V; +-10% Murata GRM39B105K6.3PT 2113928P04
C120 0.001uF; 50V; +-10% Murata GRM39B102K50PT N/A
C129 0.01uF; 50V; +-10% Murata GRM39B103K50PT N/A
C131 100pF; 50V; +-5% Murata GRM39CH101J50PT 2113740F51
C132 100pF; 50V; +-5% Murata GRM39CH101J50PT 2113740F51
C133 0.001uF; 50V; +-10% Murata GRM39B102K50PT N/A
C134 0.01uF; 50V; +-10% Murata GRM39B103K50PT N/A
C135 2.2uF; 6.3V; +-10% Murata GRM40B225K6.3PT N/A
C136 0.22uF; 10V; +-10% Murata GRM39B224K10PT 2113928G01
C137 0.1uF; 25V; +-10% Murata GRM39B104K25PT N/A
C138 0.1uF; 25V; +-10% Murata GRM39B104K25PT N/A
C139 0.1uF; 25V; +-10% Murata GRM39B104K25PT N/A
C140 0.22uF; 10V; +-10% Murata GRM39B224K10PT 2113928G01
C141 0.001uF; 50V; +-10% Murata GRM39B102K50PT N/A
C142 0.001uF; 50V; +-10% Murata GRM39B102K50PT N/A
C143 0.001uF; 50V; +-10% Murata GRM39B102K50PT N/A
C144 0.001uF; 50V; +-10% Murata GRM39B102K50PT N/A
C145 47pF; 50V; +-5% Murata GRM39CH470J50PT 2113740F43
C146 0.001uF; 50V; +-10% Murata GRM39B102K50PT N/A
C147 0.001uF; 50V; +-10% Murata GRM39B102K50PT N/A
C148 0.001uF; 50V; +-10% Murata GRM39B102K50PT N/A
C149 0.001uF; 50V; +-10% Murata GRM39B102K50PT N/A
C150 0.001uF; 50V; +-10% Murata GRM39B102K50PT N/A
C151 0.001uF; 50V; +-10% Murata GRM39B102K50PT N/A
C152 0.001uF; 50V; +-10% Murata GRM39B102K50PT N/A
C153 0.001uF; 50V; +-10% Murata GRM39B102K50PT N/A
C154 0.001uF; 50V; +-10% Murata GRM39B102K50PT N/A
C155 0.001uF; 50V; +-10% Murata GRM39B102K50PT N/A
C156 0.01uF; 50V; +-10% Murata GRM39B103K50PT N/A
C157 0.01uF; 50V; +-10% Murata GRM39B103K50PT N/A
C158 47pF; 50V; +-5% Murata GRM39CH470J50PT 2113740F43
C159 47pF; 50V; +-5% Murata GRM39CH470J50PT 2113740F43
C160 47pF; 50V; +-5% Murata GRM39CH470J50PT 2113740F43
C161 0.001uF; 50V; +-10% Murata GRM39B102K50PT N/A
C162 0.001uF; 50V; +-10% Murata GRM39B102K50PT N/A
C163 0.001uF; 50V; +-10% Murata GRM39B102K50PT N/A
C164 0.001uF; 50V; +-10% Murata GRM39B102K50PT N/A
C165 0.001uF; 50V; +-10% Murata GRM39B102K50PT N/A
C166 47pF; 50V; +-5% Murata GRM39CH470J50PT 2113740F43
C167 47pF; 50V; +-5% Murata GRM39CH470J50PT 2113740F43
C171 0.1uF; 16V; +-10% Murata GRM39B104K16PT N/A
C173 2.2uF; 6.3V; +-10% Murata GRM40B225K6.3PT N/A
TRANSISTOR
:
Q102 Dual NPN Rohm UMG2N TR N/A
Q117 NPN Rohm DTC114EETL N/A
Q119 Dual NPN Rohm UMH6N TR 4880439V02
Q123 PNP Rohm DTA144EETL N/A
Q124 NPN Rohm DTC144EETL 4880048M03
Q130 FET Toshiba SSM3K03FE-TE85L N/A
DIODE
:
Q126 Single Rohm RB521S-30 TE61 4805656W22
Q127 Single Rohm 1SS355 TE-17 4870360C15
INTEGRATED CIRCUIT
:
Q105 ÒIC, CPU Reset Ò Rico RN5VD30CATR N/A
Q114 ÒIC, EEPROMÓ Seiko El. S-24C16AFJ-01 DSIC510003
Q120 ÒIC, DTMF DecoderÓ Sanyo LC73881M DSIC092007
Q121 ÒIC, D/A ConverterÓ Fujitsu MB88347PFV DSIC042002
Q122 ÒIC, D Flip-ßopÓ Toshiba TC7W74FU TE12L DSIC013029
Q125 ÒIC, Op-AmpÓ JRC NJM2107F (TE1) DSIC025016
LIGHT EMITTING DIODE
:
Q115 Green Stanley PG1101F-TR N/A
Q116 Green Stanley PG1101F-TR N/A
Q118 Green/Red/Amber Rohm SML-020MLT T86NN 4804810T02
COIL
:
L112 10uH Taiyo Uden LEM2520T100J N/A
JACK
:
CN101 Connector Matsushita AXK5S40245J/P DSCN097002
S101 Tact Switch Motorola Y39A33110FP 4080523Z01
S102 Tact Switch Motorola Y39A33110FP 4080523Z01
MODULE
:
Q101 CPU Sanyo LC87F72C8A DSIC092009
LC101 LCD Picvue HT138ZAS DSLC170003
M101 Capacitor Microphone Bosung OB-22P44 DSMI505001
CRYSTAL
:
X101 ÒFilter, 8.388608 MHzÓ Daishinkuu AT-38 DSXT182001
RESISTOR
:
R101 470 ohm; 0.1W; +-5% Rohm MCR03 EZHJ 470 0662057A41
R102 47 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 473 0662057A89
R104 0 ohm; 0.1W; +-5% Rohm MCR03 EZHJ 000 0662057B47
R105 10 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 103 0662057A73
R107 470 ohm; 0.1W; +-5% Rohm MCR03 EZHJ 470 0662057A17
R108 330 ohm; 0.1W; +-5% Rohm MCR03 EZHJ 331 0662057A37
R109 330 ohm; 0.1W; +-5% Rohm MCR03 EZHJ 331 0662057A37
Circuit Ref Description Vendor
Vendor Part
Number
Motorola Equivalent
Part Number
