Motorola GP2000

Circuit Board/Schematic Diagrams and Parts List Section 7 -19
VHF 136-174 MHz Radio Parts List (RF Board)
R110 51 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 513 0662057A90
R111 51 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 513 0662057A90
R112 13 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 133 0662057A76
R113 22 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 223 0662057A81
R114 43 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 433 0665027A88
R115 130 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 134 0662257B01
R116 18 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 183 0662057A79
R117 33 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 333 0662057A85
R118 100 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 104 0662057A97
R119 0 ohm; 0.1W; +-5% Rohm MCR03 EZHJ 000 0662057B47
R120 0 ohm; 0.1W; +-5% Rohm MCR03 EZHJ 000 0662057B47
R126 10 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 103 0662057A73
R127 12.4 K ohm; 0.1W; +-1% Rohm MCR03 EZHF 1242 0662057P69
R128 6.98 K ohm; 0.1W; +-1% Rohm MCR03 EZHF 6981 0662057Y24
R129 1 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 102 0662057A49
R134 1 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 102 0662057A49
R135 10 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 103 0662057A73
R136 10 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 103 0662057A73
R137 1 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 102 0662057A49
R138 10 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 103 0662057A73
R141 20 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 203 0662057A80
R142 20 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 203 0662057A80
R143 20 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 203 0662057A80
R144 20 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 203 0662057A80
R145 20 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 203 0662057A80
R146 20 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 203 0662057A80
R147 20 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 203 0662057A80
R148 20 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 203 0662057A80
R150 22 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 223 0662057A81
R153 10 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 103 0662057A73
R154 47 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 473 0662057A89
R156 47 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 473 0662057A89
R158 470 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 474 0662057B14
R159 20 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 203 0662057A80
R160 10 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 103 0662057A73
R161 10 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 103 0662057A73
R162 10 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 103 0662057A73
R163 10 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 103 0662057A73
R164 10 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 103 0662057A73
R165 10 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 103 0662057A73
R166 10 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 103 0662057A73
R167 47 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 473 0662057A89
R168 47 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 473 0662057A89
R169 330 ohm; 0.1W; +-5% Rohm MCR03 EZHJ 331 0662057A37
R170 47 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 473 0662057A89
R171 47 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 473 0662057A89
R172 47 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 473 0662057A89
R173 4.7 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 472 0662057A65
R174 4.7 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 472 0662057A65
R175 4.7 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 472 0662057A65
R176 22 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 223 0662057A81
Circuit Ref Description Vendor
Vendor Part
Number
Motorola Equivalent
Part Number
R177 2.7 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 272 0662057A59
R180 560 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 564 0662057B16
R182 0 ohm; 0.1W; +-5% Rohm MCR10 EZH J 000 0662057C01
R183 47 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 473 0662057A89
Circuit Ref Description Vendor
Vendor Part
Number
Motorola Equivalent
Part Number
CAPACITOR
C201 0.01uF; 50V; +-10% Murata GRM39B103K50PT N/A
C202 10uF; 6.3V; +-20% NEC TEMSVA0J106M8R N/A
C203 1uF; 16V; +-20% NEC TESVA1C105M1-8R N/A
C204 0.01uF; 50V; +-10% Murata GRM39B103K50PT N/A
C205 0.01uF; 50V; +-10% Murata GRM39B103K50PT N/A
C206 0.001uF; 50V; +-10% Murata GRM39B102K50PT N/A
C207 10uF; 6.3V; +-20% NEC TEMSVA0J106M8R N/A
C208 0.001uF; 50V; +-10% Murata GRM39B103K50PT N/A
C209 0.001uF; 50V; +-10% Murata GRM39B102K50PT N/A
C210 0.001uF; 50V; +-10% Murata GRM39B102K50PT N/A
C211 0.001uF; 50V; +-10% Murata GRM39B102K50PT N/A
C212 0.001uF; 50V; +-10% Murata GRM39B102K50PT N/A
C213 10uF; 6.3V; +-20% NEC TEMSVA0J106M8R N/A
C214 0.001uF; 50V; +-10% Murata GRM39B102K50PT N/A
C215 2.2uF; 6.3V; +-10% Murata GRM40F225Z16PT 2113743F18
C217 0.1uF; 16V; +-10% Murata GRM39B104K16PT N/A
C218 0.001uF; 50V; +-10% Murata GRM39B102K50PT N/A
C301 10uF; 6.3V; +-20% NEC TEMSVA0J106M8R N/A
C302 0.1uF; 16V; +-10% Murata GRM39B104K16PT N/A
C303 0.022uF; 50V; +-10% Murata GRM39B223K50PT N/A
C304 10uF; 6.3V; +-20% NEC 16MCM106MB2TER N/A
C305 0.22uF; 10V; +-10% Murata GRM39B224K10PT 2113928G01
C308 10pF; 50V; +-0.5pF Murata GRM39CH100D50PT 2113740F27
C309 0.001uF; 50V; +-10% Murata GRM39B102K50PT N/A
C310 0.001uF; 50V; +-10% Murata GRM39B102K50PT N/A
C311 0.001uF; 50V; +-10% Murata GRM39B102K50PT N/A
C312 10pF; 50V; +-0.5pF Murata GRM39CH100D50PT 2113740F27
C313 15pF; 50V; +-5% Murata GRM39CH150J50PT 2113740F31
C316 0.01uF; 50V; +-10% Murata GRM39B103K50PT N/A
C317 47pF; 50V; +-5% Murata GRM39CH470J50PT 2113740F43
C318 47pF; 50V; +-5% Murata GRM39CH470J50PT 2113740F43
C319 47pF; 50V; +-5% Murata GRM39CH470J50PT 2113740F43
C323 2.2uF; 16V; +-20% NEC TEMSVA1C225M8R N/A
C324 10uF; 16V; +-20% NEC 16MCM106MB2TER N/A
C325 Not Placed ------------ ------------ ------------
C326 Not Placed ------------ ------------ ------------
C327 Not Placed ------------ ------------ ------------
C328 Not Placed ------------ ------------ ------------
C333 0.01uF; 50V; +-10% Murata GRM39B103K50PT N/A
C335 10pF Murata TZV02Z100A110T00 N/A
Circuit Ref Description Vendor
Vendor Part
Number
Motorola Equivalent
Part Number
