Motorola GP2000 Service Manual

Section 7 -20 Circuit Board/Schematic Diagrams and Parts List
C336 33pF; 50V; +-5% Murata GRM39UJ330J50PT N/A
C337 15pF; 50V; +-5% Murata GRM39CH150J50PT 2113740F31
C338 7pF; 50V; +-0.5pF Murata GRM39UJ070D50PT N/A
C339 0.001uF; 50V; +-10% Murata GRM39B102K50PT N/A
C341 0.1uF; 16V; +-10% Murata GRM39B104K16PT N/A
C343 10uF; 6.3V; +-20% NEC TEMSVA0J106M8R N/A
C344 13pF; 50V; +-5% Murata GRM39CH130J50PT 2113740F30
C345 5pF; 50V; +-0.25pF Murata GRM39CH050C50PT N/A
C346 0.1uF; 16V; +-10% Murata GRM39B104K16PT N/A
C347 0.001uF; 50V; +-10% Murata GRM39B102K50PT N/A
C348 0.01uF; 50V; +-10% Murata GRM39B103K50PT N/A
C349 0.1uF; 16V; +-10% Murata GRM39B104K16PT N/A
C350 56pF; 50V; +-5% Murata GRM39CH560J50PT 2113740F45
C351 68pF; 50V; +-5% Murata GRM39CH680J50PT 2113740F47
C352 1.5pF; 50V; +-0.25pF Murata GRM39CK1R5C50PT N/A
C353 0.1uF; 16V; +-10% Murata GRM39B104K16PT N/A
C354 1.5pF; 50V; +-0.25pF Murata GRM39CK1R5C50PT N/A
C355 22pF; 50V; +-5pF Murata GRM39CH220J50PT 2113740F35
C357 15pF; 50V; +-5% Murata GRM39CH150J50PT 2113740F31
C358 33pF; 50V; +-5% Murata GRM39CH330J50PT 2113740F39
C359 9pF; 50V; +-0.5pF Murata GRM39CH090D50PT N/A
C360 Not Placed ------------ ------------ ------------
C361 470pF; 50V; +-10% Murata GRM39B471K50PT N/A
C362 2.2uF; 10V; +-20% NEC TESVA1A225M1-8R N/A
C363 0.001uF; 50V; +-10% Murata GRM39B102K50PT N/A
C366 10uF; 10V; +-20% NEC TESVA1A106M8R N/A
C367 0.01uF; 50V; +-10% Murata GRM39B103K50PT N/A
C368 1uF; 6.3V; +-10% Murata GRM39B105K6.3PT 2113928P04
C369 0.22uF; 35V; +-20% NEC TESVA1V224M8R N/A
C370 Not Placed ------------ ------------ ------------
C371 1uF; 16V; +-20% NEC TESVA1C105M1-8R N/A
C380 8pF; 50V; +-0.5pF Murata GRM39CH080D50PT N/A
C381 Not Placed ------------ ------------ ------------
C401 13pF; 50V; +-5% Murata GRM39CH130J50PT 2113740F30
C402 150pF; 50V; +-5% Murata GRM39CH151J50PT 2113740F55
C403 Not Placed ------------ ------------ ------------
C404 20pF; 50V; +-5% Murata GRM39CH200J50PT 2113740F34
C405 Not Placed ------------ ------------ ------------
C406 150pF; 50V; +-5% Murata GRM39CH151J50PT 2113740F55
C407 0.1uF; 16V; +-10% Murata GRM39B104K16PT N/A
C408 120pF; 50V; +-5% Murata GRM39CH121J50PT 2113740F53
C409 100pF; 50V; +-5% Murata GRM39CH101J50PT 2113740F51
C410 330pF; 50V; +-10% Murata GRM39B331K50PT N/A
C411 100pF; 50V; +-5% Murata GRM39CH101J50PT 2113740F51
C412 0.022uF; 50V; +-10% Murata GRM39B223K50PT N/A
C413 0.1uF; 16V; +-10% Murata GRM39B104K16PT N/A
C414 330pF; 50V; +-10% Murata GRM39B331K50PT N/A
C415 150pF; 50V; +-5% Murata GRM39CH151J50PT 2113740F55
C416 Not Placed ------------ ------------ ------------
C417 16pF; 50V; +-5% Murata GRM39CH160J50PT 2113740F32
C418 100pF; 50V; +-5% Murata GRM39CH101J50PT 2113740F51
Circuit Ref Description Vendor
Vendor Part
Number
Motorola Equivalent
Part Number
C419 100pF; 50V; +-5% Murata GRM39CH101J50PT 2113740F51
C420 330pF; 50V; +-10% Murata GRM39B331K50PT N/A
C421 Not Placed ------------ ------------ ------------
C422 150p; 50V; +-0.5pF Murata GRM39CH100D50PT 2113740F27
C423 Not Placed ------------ ------------ ------------
C424 10pF; 50V; +-0.5pF Murata GRM39CH100D50PT 2113740F27
C425 20pF; 50V; +-5% Murata GRM39CH200J50PT 2113740F34
C426 10pF; 50V; +-0.5pF Murata GRM39CH100D50PT 2113740F27
C427 47pF; 50V; +-5% Murata GRM39CH470J50PT 2113740F43
C428 Not Placed ------------ ------------ ------------
C429 0.022uF; 50V; +-10% Murata GRM39B223K50PT N/A
C430 22pF; 50V; +-5% Murata GRM39CH220J50PT 2113740F35
C431 22pF; 50V; +-5% Murata GRM39CH220J50PT 2113740F35
C432 82pF; 50V; +-5% Murata GRM39CH820J50PT 2113740F49
C433 27pF; 50V; +-5% Murata GRM39CH270J50PT 2113740F37
C434 Not Placed ------------ ------------ ------------
C436 0.01uF; 50V; +-10% Murata GRM39B103K50PT N/A
C437 56pF; 50V; +-10% Murata GRM39CH560J50PT 2113740F45
C438 120pF; 50V; +-5% Murata GRM39CH121J50PT 2113740F53
C439 7pF; 50V; +-0.5pF Murata GRM39CH070D50PT N/A
C440 12pF; 50V; +-5% Murata GRM39CH120J50PT 2113740F29
C441 12pF; 50V; +-5% Murata GRM39CH120J50PT 2113740F29
C442 10pF; 50V; +-5% Murata GRM39CH100J50PT N/A
C443 24pF; 50V; +-5% Murata GRM39CH240J50PT 2113740F36
C444 33pF; 50V; +-5% Murata GRM39CH330J50PT 2113740F39
C445 12pF; 50V; +-5% Murata GRM39CH120J50PT 2113740F29
C446 9pF; 50V; +-0.5pF Murata GRM39CH090D50PT N/A
C447 18pF; 50V; +-5% Murata GRM39CH180J50PT 2113740F33
C448 22pF; 50V; +-5% Murata GRM39CH220J50PT 2113740F35
C449 0.022uF; 50V; +-10% Murata GRM39B223K50PT N/A
C450 Not Placed ------------ ------------ ------------
C451 120pF; 50V; +-5% Murata GRM39CH121J50PT 2113740F53
C452 150pF; 50V; +-5% Murata GRM39CH151J50PT 2113740F55
C453 1uF; 16V; +-10% Murata GRM40B105K16PT 2113743A31
C454 0.0033uF; 50V; +-10% Murata GRM39B332K50PT 2155169M15
C455 220pF; 50V; +-10% Murata GRM39B221K50PT N/A
C456 22pF; 50V; +-5% Murata GRM39CH220J50PT 2113740F35
C457 330pF; 50V; +-10% Murata GRM39B331K50PT N/A
C458 0.001uF; 50V; +-10% Murata GRM39B102K50PT N/A
C459 0.022uF; 50V; +-10% Murata GRM39B223K50PT N/A
C460 27pF; 50V; +-5% Murata GRM39CH270J50PT 2113740F37
C461 0.022uF; 50V; +-10% Murata GRM39B223K50PT N/A
C462 330pF; 50V; +-10% Murata GRM39B331K50PT N/A
C463 47pF; 50V; +-5% Murata GRM39CH470J50PT 2113740F43
C464 Not Placed ------------ ------------ ------------
C465 Not Placed ------------ ------------ ------------
C466 0.022uF; 50V; +-10% Murata GRM39B223K50PT N/A
C467 3pF; 50V; +-0.25pF Murata GRM39CJ030C50PT 2103689A09
C468 22pF; 50V; +-5% Murata GRM39CH220J50PT 2113740F35
C469 10pF; 50V; +-0.5pF Murata GRM39CH100D50PT 2113740F27
C470 5pF; 50V; +-0.25pF Murata GRM39CH050C50PT N/A
Circuit Ref Description Vendor
Vendor Part
Number
Motorola Equivalent
Part Number
