Motorola GP2000 Service Manual

Circuit Board/Schematic Diagrams and Parts List Section 7 -21
C471 5pF; 50V; +-0.25pF Murata GRM39CH050C50PT N/A
C473 0.001uF; 50V; +-10% Murata GRM39B102K50PT N/A
C474 0.01uF; 50V; +-10% Murata GRM39B103K50PT N/A
C475 22pF; 50V; +-5% Murata GRM39CH220J50PT 2113740F35
C476 0.001uF; 50V; +-10% Murata GRM39B102K50PT N/A
C477 0.001uF; 50V; +-10% Murata GRM39B102K50PT N/A
C478 5pF; 50V; +-0.25pF Murata GRM39CH050C50PT N/A
C479 0.001uF; 50V; +-10% Murata GRM39B102K50PT N/A
C480 0.001uF; 50V; +-10% Murata GRM39B102K50PT N/A
C481 0.001uF; 50V; +-10% Murata GRM39B102K50PT N/A
C482 0.01uF; 50V; +-10% Murata GRM39B103K50PT N/A
C483 0.001uF; 50V; +-10% Murata GRM39B102K50PT N/A
C484 6.8uF; 6.3V; +-20% NEC TEMSVA0J685M8R N/A
C485 2.2uF; 16V; +-0% Murata GRM40F225Z16PT 2113743F18
C486 33pF; 50V; +-5% Murata GRM39CH330J50PT 2113740F39
C487 Not Placed ------------ ------------ ------------
C489 0.001uF; 50V; +-10% Murata GRM39B102K50PT N/A
C490 100pF; 50V; +-5% Murata GRM39CH101J50PT 2113740F51
C493 0.01uF; 50V; +-10% Murata GRM39B103K50PT N/A
C495 18pF; 50V; +-5% Murata GRM39CH180J50PT 2113740F33
C501 0.001uF; 50V; +-10% Murata GRM39B102K50PT N/A
C502 0.01uF; 50V; +-10% Murata GRM39B103K50PT N/A
C503 0.01uF; 50V; +-10% Murata GRM39B103K50PT N/A
C504 0.1uF; 25V; +-10% Murata GRM39B104K25PT N/A
C505 100pF; 50V; +-5% Murata GRM39CH101J50PT 2113740F51
C506 0.1uF; 16V; +-10% Murata GRM39B104K16PT N/A
C508 470pF; 50V; +-10% Murata GRM39B471K50PT N/A
C509 0.001uF; 50V; +-10% Murata GRM39B102K50PT N/A
C510 0.22uF; 10V; +-10% Murata GRM39B224K10PT 2113928G01
C511 0.1uF; 16V; +-10% Murata GRM39B104K16PT N/A
C512 0.0022uF; 50V; +-10% Murata GRM39B222K50PT N/A
C513 27pF; 50V; +-5% Murata GRM39CH270J50PT 2113740F37
C514 0.01uF; 50V; +-10% Murata GRM39B103K50PT N/A
C515 0.01uF; 16V; +-2% Panasonic ECHU1C103GX5 DSCF097003
C516 0.01uF; 16V; +-2% Panasonic ECHU1C103GX5 DSCF097003
C517 0.01uF; 16V; +-2% Panasonic ECHU1C103GX5 DSCF097003
C518 0.01uF; 16V; +-2% Panasonic ECHU1C103GX5 DSCF097003
C519 0.01uF; 50V; +-10% Murata GRM39B103K50PT N/A
C520 0.01uF; 16V; +-2% Panasonic ECHU1C103GX5 DSCF097003
C521 0.01uF; 16V; +-2% Panasonic ECHU1C103GX5 DSCF097003
C522 0.01uF; 16V; +-2% Panasonic ECHU1C103GX5 DSCF097003
C523 0.22uF; 50V; +-10% Murata GRM39B224K10PT 2113928G01
C524 0.068uF; 16V; +-10% Murata GRM39B683K16PT N/A
C525 33pF; 50V; +-5% Murata GRM39CH330J50PT 2113740F39
C526 39pF; 50V; +-5% Murata GRM39CH390J50PT 2113740F41
C527 0.01uF; 50V; +-10% Murata GRM39B102K50PT N/A
C528 1uF; 6.3V; +-10% Murata GRM39B105K6.3PT 2113928P04
C529 0.1uF; 16V; +-10% Murata GRM39B104K16PT N/A
C530 0.1uF; 16V; +-10% Murata GRM39B104K16PT N/A
C531 220pF; 50V; +-10% Murata GRM39B221K50PT N/A
C532 220pF; 50V; +-10% Murata GRM39B221K50PT N/A
Circuit Ref Description Vendor
Vendor Part
Number
Motorola Equivalent
Part Number
C533 47pF; 50V; +-5% Murata GRM39CH470J50PT 2113740F43
C534 2.2uF; 10V; +-20% NEC TESVA1A225M1-8R N/A
C535 0.027uF; 25v; +-10% Murata GRM39B273K25PT 2155169N29
C536 0.047uF; 16V; +-10% Murata GRM39B473K16PT N/A
C537 0.0027uF; 50V; +-10% Murata GRM39B272K50PT 21SW973A115
C538 0.01uF; 16V; +-2% Murata GRM39B103K50PT N/A
C539 0.039uF; 16v; +-10% Murata GRM39B393K16PT N/A
C540 0.0015uF; 50V; +-10% Murata GRM39B152K50PT 2155169M11
C541 0.1uF; 16V; +-10% Murata GRM39B104K16PT N/A
C542 390pF; 50V; +-10% Murata GRM39B391K50PT 2113741F15
C543 0.0047uF; 50V; +-10% Murata GRM39B472K50PT N/A
C544 0.22uF; 10V; +-10% Murata GRM39B224K10PT 2113928G01
C545 33uF; 6.3V; +-20% NEC TEMSVB20J336M8R N/A
C546 0.1uF; 16V; +-10% Murata GRM39B104K16PT N/A
C547 0.1uF; 16V; +-10% Murata GRM39B104K16PT N/A
C550 0.22uF; 10V; +-10% Murata GRM39B224K10PT 2113928G01
C551 0.01uF; 16V; +-2% Panasonic ECHU1C103GX5 DSCF097003
C601 0.01uF; 50V; +-10% Murata GRM39B103K50PT N/A
C602 0.0033uF; 50V; +-10% Murata GRM39B332K50PT 2155169M15
C603 82pF; 50V; +-5% Murata GRM39CH820J50PT 2113740F49
C604 0.0012uF; 50V; +-10% Murata GRM39B122K50PT N/A
C605 680pF; 50V; +10% Murata GRM39B681K50PT N/A
C606 0.047uF; 16V; +-10% Murata GRM39B473K16PT N/A
C607 0.1uF; 16V; +-10% Murata GRM39B104K16PT N/A
C608 Not Placed ------------ ------------ ------------
C612 10pF; 50V; +-0.5pF Murata GRM39CH100D50PT 2113740F27
C615 0.01uF; 50V; +-10% Murata GRM39B103K50PT N/A
C616 0.027uF; 25V; +-10% Murata GRM39B273K25PT 2155169N29
C617 0.047uF; 25V; +-10% Murata GRM39B472K50PT N/A
C618 82pF; 50V; +-5% Murata GRM39CH820J50PT 2113740F49
C619 0.1uF; 16V; +-10% Murata GRM39B104K16PT N/A
C620 0.22uF; 10V; +-10% Murata GRM39B224K10PT 2113928G01
C621 0.001uF; 50V; +-10% Murata GRM39B102K50PT N/A
C622 0.001uF; 50V; +-10% Murata GRM39B102K50PT N/A
C623 0.01uF; 16V; +-2% Murata GRM39B103K50PT N/A
C624 220pF; 50V; +-10% Murata GRM39B221K50PT N/A
C625 4.7uF; 6.3V; +-20% NEC TEMSVA0J475M8R N/A
C626 10uF; 6.3V; +-20% NEC TEMSVA0J106M8R N/A
C627 470pF; 50V; +-10% Murata GRM39B471K50PT N/A
C628 1uF; 16V; +-20% NEC TESVA1C105M1-8R N/A
C629 1pF; 6.3V; +-10% Murata GRM39B105K6.3PT 2113928P04
C630 0.015uF; 50V; +-10% Murata GRM39B153K50PT 2113932E03
C631 0.082uF; 50V; +-10% Murata GRM39B822K50PT N/A
C632 68pF; 50V; +-5% Murata GRM39CH680J50PT 2113740F47
C633 0.01uF; 50V; +-10% Murata GRM39B103K50PT N/A
C634 0.0018uF; 50V; +-10% Murata GRM39B182K50PT 2155116E54
C635 0.1uF; 16V; +-10% Murata GRM39B104K16PT N/A
C636 100pF; 50V; +-5% Murata GRM39CH101J50PT 2113740F51
C637 2.2uF; 6.3V; +-20% Murata GRM40B225K6.3PT N/A
C638 4.7uF; 6.3V; +-20% NEC TEMSVA0J475M8R N/A
C639 27pF; 50V; +-5% Murata GRM39CH270J50PT 2113740F37
Circuit Ref Description Vendor
Vendor Part
Number
Motorola Equivalent
Part Number

Motorola GP2000 Specifications

General

Sealing	IP54
Channel Capacity	16 channels
Power Output	5W
Battery Life	8 hours
Weight	350 g
