5A-28 Circuit Board/Schematic Diagrams and Parts List
C3818 2113743E07 0.022 uF
C3821 2113743L41 10000 pF, 10%
C3822 2113743L17 1000 pF, 10%
C3823 2113743L41 10000 pF, 10%
C3824 2113743N44 56.0 pF, 5%
C3825 2113743N30 15.0 pF, 5%
C3826 2113743N18 4.7 pF, 0.25 pF
C3827 2113743E07 0.022 uF
C3828 2185895Z01 0.01 uF
C3829 2185895Z01 0.01 uF
C3830 2113743N46 68.0 pF, 5%
C3832 2113743L17 1000 pF, 10%
C3833 2113743N18 4.7 pF, 0.25 pF
C3834 2113743N44 56.0 pF, 5%
C3835 2113743N22 6.8 pF, 0.5 pF
C3836 2113743N30 15.0 pF, 5%
C3842 2113743L17 1000 pF, 10%
C502 2311049A05 0.47 uF, 10%
C503 2113743N50 100 pF, 5%
C505 2113743N50 100 pF, 5%
C511 2113743N50 100 pF, 5%
C512 2113743N50 100 pF, 5%
C513 2113743N50 100 pF, 5%
C514 2113743N50 100 pF, 5%
C520 2113743L41 10000 pF, 10%
C521 2113743L41 10000 pF, 10%
C522 2113743L41 10000 pF, 10%
C523 2113743L17 1000 pF, 10%
C525 2113743L09 470 pF, 10%
C526 2113743L09 470 pF, 10%
C527 2113743L09 470 pF, 10%
C528 2113743L09 470 pF, 10%
C529 2113743L09 470 pF, 10%
C530 2113743L09 470 pF, 10%
C531 2113743L09 470 pF, 10%
C532 2113743L09 470 pF, 10%
C533 2113743L09 470 pF, 10%
C534 2113743L09 470 pF, 10%
C535 2113743L09 470 pF, 10%
C536 2113743L09 470 pF, 10%
C537 2113743L09 470 pF, 10%
C538 2113743L09 470 pF, 10%
C539 NOT PLACED
C540 NOT PLACED
C541 NOT PLACED
C542 NOT PLACED
C543 NOT PLACED
C544 2113743L09 470 pF, 10%
C545 2113743L09 470 pF, 10%
C546 2113743L09 470 pF, 10%
C547 2113743L09 470 pF, 10%
Circuit
Ref
Motorola
Part No.
Description
C548 NOT PLACED
C549 2113743L09 470 pF, 10%
C550 2113743L09 470 pF, 10%
C551 2113743L09 470 pF, 10%
C552 2113743L09 470 pF, 10%
C553 2113743L09 470 pF, 10%
C555 2113743L09 470 pF, 10%
CR3301 4802245J42 Ring Quad Diode
CR3302 4805129M96 Dual Bond Diode
CR3303 4880154K03 Dual Diode MMBD353
CR501 4880107R01 Rectifier
CR503 4805729G49 Red / Yellow Diode
D3270 4862824C01 Varactor Diode
D3301 4802081B58 Dual Diode
D3302 4802081B58 Dual Diode
D3521 4880973Z02 PIN Diode
D3551 4880973Z02 PIN Diode
D3701 4802233J09 Triple Diode
D3702 4802233J09 Triple Diode
D3761 4862824C03 Varactor Diode
D3821 4805649Q13 Varactor Diode
D3831 4805649Q13 Varactor Diode
D3832 4862824C01 Varactor Diode
F501 6580542Z01 Fuse 3A
H3501 2680499Z01 Heat Spreader
J200 0905505Y04 Conn ZIF Horizontal
J3501 0985613Z01 RF Jack
J3502 0280519Z02 Antenna Nut
(Ref: 0280519Z04)
L3200 2462587N68 1000 nH, 5%
L3201 NOT PLACED
L3202 2462587N68 1000 nH, 5%
L3221 2462587N68 1000 nH, 5%
L3270 2462587T15 100 nH, 5%
L3271 2462587Q20 2200 nH, 20%
L3301 2462587T35 12 nH, 5%
L3303 2462587T35 12 nH, 5%
L3304 2462587T23 470 nH, 5%
L3305 2462587T35 12 nH, 5%
L3306 2462587T35 12 nH, 5%
L3308 2462587T34 10 nH, 5%
L3309 2462587N55 150 nH, 5%
L3312 2462587V28 33 nH, 5%
L3501 2413926H09 5.6 nH, 0.3 nH
L3503 2462587V32 68 nH, 5%
L3504 2462587N51 68 nH, 5%
L3511 2462587N44 18 nH, 5%
L3512 2479990B01 11.03 nH
L3513 2479990A02 7.66 nH
L3515 2479990C03 13.85 nH
L3518 NOT PLACED
Circuit
Ref
Motorola
Part No.
Description
L3519 2484657R01 Inductor Bead Chip
L3521 2479990A02 7.66 nH
L3522 2479990E01 23.75 nH
L3523 2462587N68 1000 nH, 5%
L3531 2479990N01 43.67 nH
L3532 2479990N01 43.67 nH
L3538 2479990M01 30.54 nH
L3551 2479990N01 43.67 nH
L3552 2479990A02 7.66 nH
L3701 2462587Q42 390 nH, 10%
L3731 2462587Q20 2200 nH, 20%
L3801 2462587V34 100 nH, 5%
L3809 2462587V27 27 nH, 5%
L3811 2462587V34 100 nH, 5%
L3812 2462587V34 100 nH, 5%
L3813 2462587Q47 1000 nH, 10%
L3816 2462587V34 100 nH, 5%
L3821 2462587N50 56 nH, 5%
L3822 2462587N49 47 nH, 5%
L3823 2462587N49 47 nH, 5%
L3824 2462587N68 1000 nH, 5%
L3825 2462587V34 100 nH, 5%
L3826 2462587N68 1000 nH, 5%
L3831 2462587N50 56 nH, 5%
L3832 2462587N51 68 nH, 5%
L3833 2462587N50 56 nH, 5%
L3834 2462587N68 1000 nH, 5%
L505 2462587Q42 390 nH, 10%
PB501 4070354A01 Light Touch Switch
PB502 4070354A01 Light Touch Switch
PB504 4070354A01 Light Touch Switch
PB505 4070354A01 Light Touch Switch
Q3200 4813827A07 Transistor NPN MMBR941
Q3201 4880214G02 Transistor MMBT3904
Q3202 4880214G02 Transistor MMBT3904
Q3270 4805218N63 RF Transistor BFQ67W
Q3301 4880214G02 Transistor MMBT3904
Q3302 4813827A07 Transistor NPN MMBR941
Q3501 4813828A08 Transistor 8W 175MHz
Q3561 4813824A17 XSTR PNP 40V
Q3721 4809939C05 Transistor Dual NPN / PNP
Q3801 4813827A07 Transistor NPN MMBR941
Q502 5180159R01 Dual Transistor NPN
Q505 4880214G02 Transistor MMBT3904
R3200 0662057M54 150 , 5%
R3201 0662057M82 2200, 5%
R3202 0662057M90 4700, 5%
R3203 0662057M98 10 k, 5%
R3204 0662057M26 10, 5%
R3205 0662057M74 1000, 5%
R3206 0662057N23 100 k, 5%
Circuit
Ref
Motorola
Part No.
Description
R3207 0662057N13 39 k, 5%
R3208 0662057M50 100, 5%
R3209 0662057M74 1000, 5%
R3210 0662057M82 2200, 5%
R3211 0662057M82 2200, 5%
R3212 0662057M90 4700, 5%
R3213 0662057M82 2200, 5%
R3214 0662057M34 22, 5%
R3218 NOT PLACED
R3219 0662057M50 100, 5%
R3220 0662057M90 4700, 5%
R3221 0662057M50 100, 5%
R3222 NOT PLACED
R3223 NOT PLACED
R3224 0662057M26 10, 5%
R3225 0662057M74 1000, 5%
R3226 0662057M26 10, 5%
R3270 0662057M74 1000, 5%
R3271 0662057M42 47, 5%
R3272 0662057N15 47 k, 5%
R3273 0662057N15 47 k, 5%
R3274 0662057M83 2400, 5%
R3275 0662057M74 1000, 5%
R3276 0662057N30 200 k, 5%
R3301 NOT PLACED
R3303 0662057N23 100 k, 5%
R3304 0662057N23 100 k, 5%
R3305 0662057N19 68 k, 5%
R3306 0662057M82 2200, 5%
R3307 0662057N11 33 k, 5%
R3308 0662057M78 1500, 5%
R3309 0662057M92 5600, 5%
R3310 0662057M98 10 k, 5%
R3311 0662057M26 10, 5%
R3312 0662057M38 33, 5%
R3313 0662057M34 22, 5%
R3314 0662057M26 10, 5%
R3315 0662057M62 330, 5%
R3316 0662057M66 470, 5%
R3317 0662057N23 100 k, 5%
R3318 0662057M66 470, 5%
R3319 NOT PLACED
R3320 NOT PLACED
R3321 0662057M54 150, 5%
R3322 0662057M58 220, 5%
R3323 0662057M32 18, 5%
R3324 0662057M58 220, 5%
R3501 0662057M61 300, 5%
R3502 0662057M32 18, 5%
R3503 0662057M61 300, 5%
R3505 0662057M62 330, 5%
Circuit
Ref
Motorola
Part No.
Description
