Circuit Board/Schematic Diagrams and Parts List 5A-27
VHF Radio Parts List (RF Board)
Circuit
Ref
Motorola
Part No.
Description
B501 0986237A02 Battery Contact Module
B501 0986237A02 Battery Contact Connector
B503 3980502Z01 Contact, Backup B+
(not used in GP328 Plus)
B504 3980501Z01 Contact, Backup B-
(not used in GP328 Plus)
C3200 2113743N31 16.0 pF, 5%
C3201 NOT PLACED
C3202 NOT PLACED
C3203 2113743N50 100 pF, 5%
C3204 2113743L41 10000 pF, 10%
C3205 2113928N01 0.1 uF, 10%
C3206 2113743L41 10000 pF, 10%
C3207 2113743N10 2.2 pF, 0.25 pF
C3208 NOT PLACED
C3209 2311049A07 1.0 uF, 10%
C3210 2113743L17 1000 pF, 10%
C3211 2311049A56 4.7 uF
C3212 2311049A07 1.0 uF, 10%
C3213 2311049A56 4.7 uF
C3214 2113928N01 0.1 uF, 10%
C3215 2113743N26 10.0 pF, 5%
C3218 2311049A56 4.7 uF
C3219 2113928N01 0.1 uF, 10%
C3220 2113743N26 10.0 pF, 5%
C3221 2113743L41 10000 pF, 10%
C3222 2113928N01 0.1 uF, 10%
C3223 2113928N01 0.1 uF, 10%
C3224 2113928N01 0.1 uF, 10%
C3225 2113928N01 0.1 uF, 10%
C3226 2113928N01 0.1 uF, 10%
C3227 2113743L41 10000 pF, 10%
C3228 2113743L41 10000 pF, 10%
C3229 2113743N50 100 pF, 5%
C3230 2113740F51 100 pF
C3231 2180478Z20 1.0 uF
C3232 2180478Z20 1.0 uF
C3233 2180478Z20 1.0 uF
C3234 2180478Z20 1.0 uF
C3235 2113743A23 0.220 uF, 10%
C3236 NOT PLACED
C3237 NOT PLACED
C3238 2113743A24 0.330 uF, 10%
C3239 2113743E07 0.022 uF
C3240 2113743A23 0.220 uF, 10%
C3241 2113743L19 1200 pF, 10%
C3242 2109720D14 0.1 uF
C3243 2113743E07 0.022 uF
C3244 2113743L41 10000 pF, 10%
C3270 2113743E07 0.022 uF
C3271 2113743L05 330 pF, 10%
C3272 2113743N18 4.7 pF, 0.25 pF
C3273 2113743N26 10.0 pF, 5%
C3274 2113743N38 33.0 pF, 5%
C3275 2113743N44 56.0 pF, 5%
C3276 2113743N42 47.0 pF, 5%
C3277 2113743N48 82.0 pF, 5%
C3278 2113743E07 0.022 uF
C3279 2311049A40 2.2 uF, 10%
C3280 2113743L41 10000 pF, 10%
C3301 2113743N20 5.6 pF, 0.5 pF
C3302 2113743N54 150 pF, 5%
C3303 2113743N30 15.0 pF, 5%
C3304 2113743N54 150 pF, 5%
C3305 NOT PLACED
C3306 2113928N01 0.1 uF, 10%
C3307 2113743N50 100 pF, 5%
C3308 2113743L05 330 pF, 10%
C3309 2113928N01 0.1 uF, 10%
C3310 NOT PLACED
C3311 2113743N54 150 pF, 5%
C3312 2113743N31 16.0 pF, 5%
C3313 2113743N54 150 pF, 5%
C3314 NOT PLACED
C3315 2113743N26 10.0 pF, 5%
C3316 2113743N14 3.3 pF, 0.25 pF
C3317 2113743N40 39.0 pF, 5%
C3318 2113743M08 22000PF, +80% / -20%
C3319 NOT PLACED
C3320 2113743N48 82.0 pF, 5%
C3321 2113743L05 330 pF, 10%
C3322 2113743N50 100 pF, 5%
C3323 2113743N50 100 pF, 5%
C3324 2113743N38 33.0 pF, 5%
C3325 2113743L17 1000 pF, 10%
C3326 NOT PLACED
C3327 2113743L05 330 pF, 10%
C3329 2113743L05 330 pF, 10%
C3330 2113743N50 100 pF, 5%
C3331 2113743N50 100 pF, 5%
C3332 2113743N40 39.0 pF, 5%
C3334 2113743N33 20.0 pF, 5%
C3335 2113743N34 22.0 pF, 5%
C3336 2311049A18 10 uF, 10%
C3337 2113743M08 22000PF, +80% / -20%
C3338 2113743L09 470 pF, 10%
C3339 2113743N26 10.0 pF, 5%
C3501 2113743L05 330 pF, 10%
C3502 2113743N38 33.0 pF, 5%
C3503 2113743N38 33.0 pF, 5%
Circuit
Ref
Motorola
Part No.
Description
C3504 2113743M08 22000PF, +80% / -20%
C3505 2113743N38 33.0 pF, 5%
C3508 2113743M08 22000PF, +80% / -20%
C3509 2113743L05 330 pF, 10%
C3512 2113740F43 47 pF
C3513 2113740F38 30 pF
C3514 2113740F47 68 pF
C3515 2113743L29 3300 pF, 10%
C3516 2311049A08 1 uF
C3517 2113740F47 68 pF
C3518 NOT PLACED
C3519 NOT PLACED
C3521 2111078B51 220 uF
C3523 2111078B44 120 uF
C3524 2113740F34 20 pF
C3525 2113740F27 10 pF
C3526 2113743M08 22000PF, +80% / -20%
C3527 NOT PLACED
C3528 2113740F27 10 pF
C3531 2113740F34 20 pF
C3532 2113740F47 68 pF
C3533 2113740F24 7.5 pF
C3534 2113740F19 4.7 pF
C3535 2113740F37 27 pF
C3536 2113740F31 15 pF
C3537 2113740F33 18 pF
C3539 2113740F29 12 pF
C3541 2113743M08 22000PF, +80% / -20%
C3542 2113743L05 330 pF, 10%
C3543 2113743M08 22000PF, +80% / -20%
C3544 2113743L05 330 pF, 10%
C3546 2113743L05 330 pF, 10%
C3547 2113743M08 22000PF, +80% / -20%
C3550 2113743N23 7.5 pF, 0.5 pF
C3551 2113743N46 68.0 pF, 5%
C3552 2113743N44 56.0 pF, 5%
C3560 2311049A07 1.0 uF, 10%
C3561 2113743M08 22000PF, +80% / -20%
C3562 2113743L29 3301 pF, 10%
C3563 2113743L29 3302 pF, 10%
C3564 2113743L01 220 pF, 10%
C3565 2113743E07 0.022 uF
C3566 2113743N50 100 pF, 5%
C3567 2113743L05 330 pF, 10%
C3568 2113743L29 3303 pF, 10%
C3569 2113743M08 22000PF, +80% / -20%
C3570 2113743L05 330 pF, 10%
C3571 2113743L09 470 pF, 10%
C3701 2113743L41 10000 pF, 10%
C3702 2113743L41 10000 pF, 10%
C3703 2113743L41 10000 pF, 10%
Circuit
Ref
Motorola
Part No.
Description
C3704 2113743L41 10000 pF, 10%
C3705 2113743E20 0.10 uF, 10%
C3706 2311049J11 4.7 uF, 10%
C3707 2113743N34 22.0 pF, 5%
C3708 2113928N01 0.1 uF, 10%
C3709 2113928N01 0.1 uF, 10%
C3710 2104993J02 2.2 uF
C3711 2311049A69 10.0 uF, 20%
C3712 2113928N01 0.1 uF, 10%
C3713 2311049A09 2.2 uF, 10%
C3714 2311049J11 4.7 uF, 10%
C3715 2113743L09 470 pF, 10%
C3721 2113743E20 0.10 uF, 10%
C3722 2113743E20 0.10 uF, 10%
C3724 2311049A08 1 uF
C3725 NOT PLACED
C3726 2113743N24 8.2 pF, 0.5 pF
C3727 2113743N50 100 pF, 5%
C3731 2113743L41 10000 pF, 10%
C3732 2113743L41 10000 pF, 10%
C3733 2104993J02 2.2 uF
C3734 2113743L41 10000 pF, 10%
C3735 NOT PLACED
C3741 NOT PLACED
C3742 2113743L01 220 pF, 10%
C3743 2113743L01 220 pF, 10%
C3744 2113743L01 220 pF, 10%
C3745 2113743L01 220 pF, 10%
C3746 2113743L01 220 pF, 10%
C3751 NOT PLACED
C3752 2113743L17 1000 pF, 10%
C3753 2311049A56 4.7 uF
C3754 2113928N01 0.1 uF, 10%
C3755 2104993J02 2.2 uF
C3761 2113743N40 39.0 pF, 5%
C3762 2113740F63 330 pF, 5%
C3763 NOT PLACED
C3801 2113743N18 4.7 pF, 0.25 pF
C3802 NOT PLACED
C3803 2113743L17 1000 pF, 10%
C3804 2113743E20 0.10 uF, 10%
C3805 2113743N18 4.7 pF, 0.25 pF
C3806 2113743N50 100 pF, 5%
C3808 2113743N30 15.0 pF, 5%
C3809 2113743N36 27.0 pF, 5%
C3810 NOT PLACED
C3811 2113928N01 0.1 uF, 10%
C3812 2113928N01 0.1 uF, 10%
C3813 2113743L41 10000 pF, 10%
C3815 2113743L17 1000 pF, 10%
C3816 2113743N22 6.8 pF, 0.5 pF
Circuit
Ref
Motorola
Part No.
Description
