32
English
FEATURES
To record a memo:
1 EnsureradioisinIDLESTATE.
2
c to enter Menu Mode.
3
+ or e until:
4
c to select.
5
+ or e until:
6
c to select.
7 Press and hold the Record/Playback button,
the Voice Storage Recording alert sounds
momentarily.
Yo u w i ll s e e :
8 Speak clearly into the radio microphone to
record your memo.
9 The Voice Storage Warning alert sounds
when the memory is nearly full.
Yo u w i ll s e e :
Voice Storage
Recorder
Recording
Storage Low
10 The Voice Storage Full alert sounds when the
memory is full and recording ceases.
Yo u w i ll s e e :
11 Release the Record/Playback button at any
time to stop recording.
12 Subsequent messages can be stored by
repeating steps 7 to 11.
Storage Full

Table of Contents

Other manuals for Motorola GP360

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Motorola GP360 and is the answer not in the manual?

Motorola GP360 Specifications

Battery IconBattery
battery life with standard high capacity NiMH battery low power11 hours
battery life with standard high capacity NiMH battery high power8 hours
battery life with ultra high capacity NiMH battery low power14 hours
battery life with ultra high capacity NiMH battery high power11 hours
battery life with NiCD battery low power12 hours
battery life with NiCD battery high power9 hours
battery life with Li-lon low power11 hours
battery life with Li-lon high power8 hours
Operating Environment IconOperating Environment
operating temperature-20°C to +55°C
sealingWithstands rain testing per MIL STD 810 C/D/E and IP54
shock and vibrationProtection via impact resistant housing exceeding MIL STD 810-C/D/E and TIA/EIA 603
dust and humidityProtection via environment resistant housing exceeding MIL STD 810 C/D/E and TIA/EIA 603
Transmitter Specifications IconTransmitter Specifications
frequencies full bandsplit VHF136-174 MHz
frequencies full bandsplit UHF403-470 MHz
channel spacing12.5/20/25 kHz
frequency stability±2.5 ppm
power VHF1-5W
power UHF1-4W
Receiver Specifications IconReceiver Specifications
frequencies full bandsplit VHF136-174 MHz
frequencies full bandsplit UHF403-470 MHz
channel spacing12.5/20/25 kHz
frequency stability±2.5 ppm
sensitivity (12 dB SINAD) EIA0.25 µV typical
sensitivity (20 dB SINAD) EN0.50 µV typical
Weight and Dimensions IconWeight and Dimensions
dimensions with standard high capacity NiMH battery137 x 57.5 x 37.5 mm
dimensions with ultra high capacity NiMH battery137 x 57.5 x 40.0 mm
dimensions with NiCD battery137 x 57.5 x 40.0 mm
dimensions with Li-lon battery137 x 57.5 x 33.0 mm
weight with standard high capacity NiMH battery428 gm
weight with ultra high capacity NiMH battery508 gm
weight with NiCD battery458 gm
weight with Li-lon battery358 gm
