GETTING STARTED
Attaching the Side Connector Cover
Antenna
Loop
Thumbscrew
Slot
1 Place the loop (attached to the side connector
cover) over the antenna; then slide it down-
ward until it touches the top of the radio.
2 Insert the tab on top of the cover into the slot
above the connector.
3 Position the cover over the connector and
align the thumbscrew with the threaded hole
in the radio.
4 Tighten the thumbscrew to hold the cover in
place. Do not overtighten the thumbscrew.
