English

RADIO OVERVIEW

This user guide covers the operation of the

GP680 Portable Radio.

Please read pages 57 to 59 before using this radio

OPERATION AND CONTROL FUNCTIONS

Radio Controls

The numbers below refer to the illustrations on

the inside front cover.

1. Rotary Knob

Used as a multi-function scroll key and as a

channel selector in Conventional mode.

2. On-Off / Volume Knob

Used to turn the radio on or off, and to adjust

the radio’s volume.

3. Clear Button (Side Button 1)

Used to cancel a call, clear down at the end of

a call or Carrier Monitor (Conventional mode).

4. Push to Talk Button (PTT)

Press and hold down this button to talk, release

it to listen.

5. Side Button 2

Personality button, otherwise programmable.

6. Side Button 3 (programmable)

7. Top Button (programmable)

Recommended as Emergency button.

8. LED Indicator

Green: Flashes to indicate NO SERVICE.

Red: On when radio is transmitting.

Red Flashing: When transmitting - battery low.

Red Flashing: When receiving - channel busy

(Conventional Mode).

9. Microphone

10. LCD Display (1 Line)

11. Menu Keys

12. Keypad

13. Antenna

14. Accessory Connector

Connects headsets, remote speaker/micro-

phones and other accessories. Replace

attached dust cap when not in use.
