71
Notes:
1. For optimum performance, order replacement diodes, transistors,
and circuit modules by Motorola part number only.
2. When ordering crystals, specify carrier frequency, crystal
frequency, crystal frequency, crystal type number, and Motorola
part number.
3. “Not Placed” means that components are for future use, and are
not placed on the circuit board at this time.
REFERENCE
SYMBOL
MOTOROLA
PART NO.
DESCRIPTION
CAPACITOR, Fixed: pF ± 25%;
50V unless stated
C1 2113930F18 4.3
C2 2113930F22 6.2
C3 2113930F18 4.3
C4 2113930F51 100
C5 2113930F23 6.8
C6 2113930F20 5.1
C7 2113930F28 11
C9 2113930F23 6.8
C10 2113930F45 56
C11 2113931F49 .01µF
C12 2113930F51 100
C13 2311049A66 22µF 4V
C15 2113930F51 100
C16 2113930F38 30
C17 2113932K15 .1µF 16V
C18 2113930F26 9.1
C19 2113930F21 5.6
C31 2113931F49 .01µF
C35 - - - - - - - - - Not Placed
C36 2113930F20 5.1
C38 2113930F27 10
C39 2113930F09 1.8
C40 2113930F51 100
C41 2113743A19 .1µF
C42 thru 46 2113743A23 .22µF
C47 2109720D14 .1µF
C48 2113741F16 430
C49 2113743F12 .330µF
C50 2113931F49 .01µF 5%
C51 2113932K15 .1µF 16V
C52 2113741A51 .018µF
C53 2113743B17 .150µF
C54 2113930F41 39
C55 2113930F39 33
C56, 57 2113930F42 43
C58 2113930F11 2.2
C59 2113931F49 .01µF 5%
C60 2113932K15 .1µF 16V
C61 2109720D14 .1µF
C63, 64 2113932K15 .1µF 16V
C65 2113931F41 .0047µF 5%
C72 2113930F51 100
C82 2113931F49 .01µF 5%
C83 2113930F51 100
C84 2113931F49 .01µF 5%
C85 2311049J23 10µF
C86, 87 2113930F51 100
C88 2113930F45 56
C89 2113740A18 4.3
C90 2113930F25 8.2
C91 2113930F31 15
C92 2113930F09 1.8
C93 2113930F20 5.1
C94 2113930F29 12
C95 2113930F25 8.2
C96 2113931F49 .01µF 5%
C98 2113930F34 20
C99 2113930F21 5.6
C101 2113932E07 .022µF 10% 16V
C102 - - - - - - - - - Not Placed
C103 2311049J26 10µF
C104, 105 2113930F51 100
C106 2311049A56 4.7µF
C107 thru 110 - - - - - - - - - Not Placed
C111, 113, 114 2113930F51 100
C115 2113932K07 .047µF 16V
C116 - - - - - - - - - Not Placed
C117 2113930F51 100
C118 2113932K15 .1µF 16V
C119 2113930F51 100
C120 - - - - - - - - - Not Placed
C121 2113930F51 100
C123 2113932K15 .1µF 16V
C125, 126 2311049A54 3.3µF
C127 - - - - - - - - - Not Placed
C128 2311049A07 1µF
C132 2113930F25 8.2
C133 2113930F09 1.8 ± 0.1
C135, 137, 138 2113930F51 100
C139 - - - - - - - - - Not Placed
C140 2113931F41 .0047µF 5%
C141, 145, 147 2113930F51 100
C148 2113930F03 1 ± 0.1
C149 2113930F30 13
C150 2113930F29 12
C151 2113930F18 4.3
C153 thru 155 2113930F51 100
C156 2311049A07 1µF
C157 2113932K15 .1µF 16V
C201 2113930F03 1 ± 0.1
C202 - - - - - - - - - Not Placed
C203 2113930F07 1.5 ± 0.1
C204 2113930F51 100
C205 - - - - - - - - - Not Placed
C206 2113931F33 .0022µF 5%
C208 2113930F51 100
C209 2113931F49 .01µF 5%
C210 2113932E07 .022µF 10% 16V
C211 2113930F51 100
C214 2113930F14 3
C216 2113931F37 .003µF 5%
C217 2113930F51 100
C219 2113930F15 3.3
C220 2113930F22 6.2
C221 2113931F49 .01µF 5%
C222 2113930F18 4.3
C223 2113906C02 ATC, 4pF
C225 2113930F03 1 ± 0.1
C226 2113930F26 9.1
C227, 228 2113930F51 100
C230 - - - - - - - - - Not Placed
C231 2311049A60 10µF 4V
C233 2113930F51 100
C235 2113930F20 5.1
C236 2113930F18 4.3
C237 2113930F15 3.3
C238 2113930F51 100
C239 2113930F23 6.8
C240 2113906C02 ATC, 4pF
C243 2113930F23 6.8
C244 2109720D09 .022µF
C245 2113931F25 .001µF 5%
C246 2109720D09 .022µF
C247 2311049A05 .47µF, 25V
C250 2113931F25 .001µF 5%
C253 2311049J23 10µF 6V
C254 2113928L05 4.7µF 16V
C255 2113932K15 .1µF 16V
C256 2113931F49 .01µF 5%
C257 2113931F49 .01µF 5%
C258 2311049J11 4.7µF 16V
C260 2113932K07 .047µF 16V
C266, 267 2113931F49 .01µF 5%
C270 2113931F25 .001µF 5%
C271 2385688A01 4.7µF 10V 20%
C274 - - - - - - - - - Not Placed
C275 2113932K15 .1µF 16V
C279 2113930F51 100
C280 2113932K15 .1µF 16V
C282 2113932K15 .1µF 16V
C284 2311049A33 0.22µF
C287 2109720D09 .022µF
C288 2113931F49 .01µF 5%
C289, 290 2113930F51 100
C292 2113930F03 1 ± 0.1
C294 2113930F51 100
C303 2113932E07 .022µF 10% 16V
C304 thru 308 2113930F51 100
C309 2113931F37 .0033µF 5%
C310 2113930F51 100
C311 2113931F37 .0033µF 5%
C313, 314 - - - - - - - - - Not Placed
C315 2113930F51 100
DIODE: See Note 1
CR5 thru 9 4862824C01 Varactor
CR11 4805129M96 PIN
CR12 4805218N57 Dual
CR101, 103 4805129M67 Dual
CR108, 109 4802482J02 PIN
CR201 4802245J29 Varactor
CR202 4862824C01 Varactor
CR203 4862824C03 Varactor
CR204, 205 4802233J09 Triple
CR206 4805129M06 Dual
CR207 thru 209 4802245J29 Varactor
CORE:
E101 2484657R01 Bead, Ferrite
E104 - - - - - - - - - Not Placed
FUSE:
F1 6505757V01 1-Amp.
FILTER:
FL1 4802655J03 Crystal, 73.35MHz, See Note 2
CONNECTOR:
G1 3905643V01 Contact, Antenna Ground
G2 3905643V01 Contact, Ground
JACK:
J301 0905461X03 Connector; 20 contacts; to P301
Strip Connector
J401 3905264W01 Contact Antenna
COIL, RF: nH
L6 2462587V29 39 5%
L7 2462587V37 180 5%
L8 2462587T23 470 5%
L9 2462587V27 27 5%
L10 2462587V23 12 5%
L11 2460591B04 4 Turns, airwound
L12 2460591M32 4 Turns, airwound
L13 2460591B80 4 Turns, airwound
L14, 15 2460591B04 4 Turns, airwound
L16 2462587T23 470 5%
L20 2462587N61 470 5%
L22 2462587T23 470 5%
L23 2462587Q44 560 10%
L24 2462587V37 180 5%
L25 2462587Q20 2, 200 20%
L30, 31 2460591A01 3 Turns, airwound
L32 2460591B04 4 Turns, airwound
L34, 35 2460591A01 3 Turns, airwound
L36 2462587V36 150 5%
L37 2462587V24 15 5%
L101 2462587T20 270 5%
L102, 103 - - - - - - - - - Not Placed
L105 2462587T20 270 5%
L107, 108 2462587T17 150 5%
L121, 122 2462587T20 270 5%
L123 2462587V38 220 5%
L126 thru 128 2460591B04 4 Turns, airwound
L201 2462587T37 18 5%
L202 2462587Q20 2200 20%
L204 2462587Q42 390 10%
L205 2462587V25 18 5%
L207 2462587V36 150 5%
L208, 209 2462587T22 390 5%
L210 2405619V03 15.1, Molded Coil
L211 2405619V07 9, Molded Coil
L212 2462587V25 18 5%
L213, 215 2462587T22 390 5%
L216 2462587T05 15 10%
L218 2462587T22 390 5%
L219 2462587T37 18 5%
L220 2462587T39 27 5%
L221 2462587T22 390 5%
L222 2462587Q40 270 10%
L223 2462587Q42 390 10%
L224 2462587T40 33 5%
L301, 302 2462587Q42 390 10%
PLUG:
P404 3905861X02 Connector, Battery; 2-pin
TRANSISTOR: See Note 1
Q1, 4 4805218N63 NPN
Q5 4880048M04 PNP
Q101 - - - - - - - - - Not Placed
Q104, 105, 107 4805921T02 PNP NPN
Q108 4802245J10 NPN Dual
Q110 4802245J12 PNP
Q201 4802245J15 JFET P-Channel
Q202 4805218N55 NPN
RESISTOR, Fixed: Ω ± 5% .0625W
unless stated
R7 0662057A25 100
R16 0662057A59 2.7K
R17 0662057A80 20K
R18 0662057B05 200K
R22, 23 0662057A73 10K
R26 Not Placed
R27 0662057A01 10
R32, 33 0662057A59 2.7K
R34, 35 0662057A89 47K
R36 - - - - - - - - - Not Placed
R40 0662057A41 470
R41 0662057A09 22
R42 0662057A41 470
R43 - - - - - - - - - Not Placed
R44 0662057A45 680
R45 0662057A90 51K
R46 0662057A89 47K
R47 0662057A09 22
R48 - - - - - - - - - Not Placed
R49 0662057A77 15K
R50 0662057A53 1.5K
R51 0662057A51 1.2K
R52 0662057A25 100
R53 0662057A73 10K
R102 0662057A65 4.7K
R106 0662057A61 3.3K
R107 - - - - - - - - - Not Placed
R110 0662057A65 4.7K
R111 0662057A49 1K
R113 0662057A85 33K
R114 0662057A77 15K
R115 0660078L28 180K ± 1%; 0.125W
R116 0662057G19 130K ± 1%; 0.1W
R119 0662057B22 1MEG
R126 0662057A18 51
R127 0662057A12 30
R128 0662057A89 47K
R129 0662057A65 4.7K
R130 - - - - - - - - - Not Placed
R139 0662057A97 100K
R199 0662057B47 0 Ω, used in place of S101 on
NUE7267B and NUE7275B
or- - - - - - - - - Not used, replaced with S101 on
NUE7268B and NUE7273B
R203 0662057A01 10
R204 0662057A73 10K
R205 0662057A77 15K
R206 0662057A73 10K
R207 0662057A93 68K
R208 0662057A58 2.4K
R209 0662057A41 470
R210 0662057A37 330
R211 0662057A29 150
R212 0662057A46 750
R213 0662057A41 470
R214 0662057A87 39K
R215 0662057A88 43K
R217 0662057A77 15K
R218 0662057A97 100K
R219 0662057B47 0 Ω ± .050 Ω
R220 0662057A56 2000
R221 0662057A51 1200
R222 - - - - - - - - - Not Placed
R223 0662057A89 47K
THERMISTOR:
RT101 0605621T02 50K
SWITCH:
S101 4005831W01 RF used on
NUE7268B and NUE7273B
or- - - - - - - - - Not used, replaced with R199 on
NUE7267B and NUE7275B
TRANSFORMER:
T1 2505515V08 Balun; 4:1
T2 2505515V11 Balun; 16:1
MODULE: See Note 1
U1 5105457W50 RF AMP
U2 5105457W52 Mixer
U3 5186296A02 IF
U101 5105835U52 TX ALC
U102 5105835U51 D/A
U103 5160880B02 5V Regulator
U104 5102001J68 Coupler
U105 5105385Y11 Power Amplifier, 4W, LDMOS
U201 5102227J37 VCO Buffer
U202 5105469E65 5V Regulator
U203 5105385Y42 Ref. 0scillator, 16.8 MHz Sine Wave
U204 5105457W81 Synthesizer
MECHANICAL PARTS
ME1 2602657J01 SHIELD, VCO
ME2 2602658J01 SHIELD, Ref. Oscillator
ME3 2602659J01 SHIELD, IF
ME4 2602660J03 SHIELD, Varactor Filter
ME5 2602832X01 SHIELD, IF Back
ME6 2602674J03 SHIELD, VCO Back
ME7 2602675J01 SHIELD, Synthesizer Back
ME8 2602686J01 SHIELD, Coil
Electrical Parts List, UHF Transceivers (450–520MHz)
NUE7267B, NUE7268B, NUE/PMUE7273B, NUE7275B
