Overview of the Parent Unit
1. Sound Level Indicators
3 GREEN and 2 RED LEDs indicate the
audio level being picked up by the
microphone of the baby unit. The more
LEDs that light up, the louder the sound
is.
If no LED lights up, the sound level in the
baby's room is below the threshold for
the parent unit.
The LEDs are also used when adjusting
the speaker volume setting on the parent
unit, with more LEDs indicating a louder
setting, from 0 to 5.
2. Link Indicator
On when the parent unit is powered on
and linked to the baby unit.
Flashes when the parent unit is out of
range of the baby unit.
3. Power
Press and hold to power on/off the
parent unit.
4. Volume +
Press to increase the speaker volume.
5. Volume -
Press to decrease the speaker volume.
6. Charging Indicator
On steadily when the mains power
adapter is connected.
Flashes when low battery is detected
during battery operation mode.
5
6
4
2
1
3
