Page #21 background imageLoading...
Page #21 background image
MC9S12DT256 Device User Guide — V03.07
21
Compatible with I2C Bus standard
Multi-master operation
Software programmable for one of 256 different serial clock frequencies
112-Pin LQFP package
I/O lines with 5V input and drive capability
5V A/D converter inputs
Operation at 50MHz equivalent to 25MHz Bus Speed
Development support
Single-wire background debug™ mode (BDM)
On-chip hardware breakpoints
1.3 Modes of Operation
User modes
Normal and Emulation Operating Modes
Normal Single-Chip Mode
Normal Expanded Wide Mode
Normal Expanded Narrow Mode
Emulation Expanded Wide Mode
Emulation Expanded Narrow Mode
Special Operating Modes
Special Single-Chip Mode with active Background Debug Mode
Special Test Mode (Motorola use only)
Special Peripheral Mode (Motorola use only)
Low power modes
Stop Mode
Pseudo Stop Mode
Wait Mode
