Motorola MC9S12DT256 User Manual

MC9S12DT256 Device User Guide — V03.07
42
$012D
ATD1DIEN
Read:
Bit 7 654321Bit 0
Write:
$012E
Reserved
Read: 00000000
Write:
$012F
PORTAD1
Read: Bit7 654321BIT 0
Write:
$0130
ATD1DR0H
Read: Bit15 14 13 12 11 10 9 Bit8
Write:
$0131
ATD1DR0L
Read: Bit7 Bit6 000000
Write:
$0132
ATD1DR1H
Read: Bit15 14 13 12 11 10 9 Bit8
Write:
$0133
ATD1DR1L
Read: Bit7 Bit6 000000
Write:
$0134
ATD1DR2H
Read: Bit15 14 13 12 11 10 9 Bit8
Write:
$0135
ATD1DR2L
Read: Bit7 Bit6 000000
Write:
$0136
ATD1DR3H
Read: Bit15 14 13 12 11 10 9 Bit8
Write:
$0137
ATD1DR3L
Read: Bit7 Bit6 000000
Write:
$0138
ATD1DR4H
Read: Bit15 14 13 12 11 10 9 Bit8
Write:
$0139
ATD1DR4L
Read: Bit7 Bit6 000000
Write:
$013A
ATD1DR5H
Read: Bit15 14 13 12 11 10 9 Bit8
Write:
$013B
ATD1DR5L
Read: Bit7 Bit6 000000
Write:
$013C
ATD1DR6H
Read: Bit15 14 13 12 11 10 9 Bit8
Write:
$013D
ATD1DR6L
Read: Bit7 Bit6 000000
Write:
$013E
ATD1DR7H
Read: Bit15 14 13 12 11 10 9 Bit8
Write:
$013F
ATD1DR7L
Read: Bit7 Bit6 000000
Write:
$0140 - $017F CAN0 (Motorola Scalable CAN - MSCAN)
Address Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
$0140
CAN0CTL0
Read:
RXFRM
RXACT
CSWAI
SYNCH
TIME WUPE SLPRQ INITRQ
Write:
$0141
CAN0CTL1
Read:
CANE CLKSRC LOOPB LISTEN
0
WUPM
SLPAK INITAK
Write:
$0142
CAN0BTR0
Read:
SJW1 SJW0 BRP5 BRP4 BRP3 BRP2 BRP1 BRP0
Write:
$0120 - $013F ATD1 (Analog to Digital Converter 10 Bit 8 Channel)
Address Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

Motorola MC9S12DT256 Specifications

General

Flash Memory	256 KB
RAM	12 KB
EEPROM	4 KB
Clock Speed	25 MHz
Timers	8
Communication Interfaces	SCI, SPI, I2C
Operating Voltage	5V
PWM Channels	8
SCI	2
SPI	1
I2C	1
Package	112-Pin LQFP
Number of I/O Pins	91
Operating Temperature Range	-40°C to +85°C
ADC Channels	8
ADC	10-bit
Architecture	16-bit HCS12
