Motorola MTP8550Ex - Removing the SIM Card Door; Removing the Knob; Figure 11: SIM Card Door Removal

5.5.2.6
Removing the SIM Card Door
Prerequisites:
Recommended tools:
• T-5IP torx-plus bit
• Torx driver
Refer to the Torque Specification Chart for torque values.
Procedure:
1 Remove the battery.
2 Using the torx driver with the T-5IP torx-plus bit, unscrew the two screws fastening the SIM card
door.
3 Remove the SIM card door from the back chassis.
Figure 11: SIM Card Door Removal
1
3
4
2
Annotation Description
1 SIM card door
2 SIM card door screws
5.5.2.7
Removing the Knob
The procedures below are for removing the knob.
MN002465A01-AN
Chapter 5 : Maintenance
62
