Motorola MTS LiTE User Manual

261
6802800U74-AN
Chapter 7: Radio Frequency Distribution System
Figure 136: MTS LiTE TX/RX on 1 ant., RX on 1 ant - Filter Configuration
DUPLEXER
BR 1 BR 2
TX
CAN 1 CAN 2
PRESELECTOR
BR 1 BR 2
Table 83: MTS 2 RF Configurations on page 261 lists all filters configurations for MTS 2 and Figure
137: MTS 2 TX/RX on 2 ant. - Filter Configuration on page 262 to Figure 140: MTS 2 TX/RX on 1 ant.,
RX on 2 ant - Filter Configuration on page 263 show the positions of filters in the filter tray.
Table 83: MTS 2 RF Configurations
Max Power [W]
Hybrid
Duplex- Preselec-
RF Configuration
Low
High
Combin-
er tor
Pwr
Pwr
er
TX/RX on 2 ant.
25
40 (20)
-
2
-
TX/RX on 2 ant., RX on 1
ant.
25
40 (20)
-
2
1
TX/RX on 1 ant., RX on 1
ant.
10
25 (10)
1
1
1
TX/RX on 1 ant., RX on 2
ant.
10
25 (10)
1
1
2
