8
English
OPERATING INSTRUCTIONS
Single-unit chargers will charge only the Motorola
Solutions authorized batteries listed in Table 1 on
page 5 Other batteries may not charge.
The battery charger’s pocket will accommodate
either a radio with a battery attached or a battery
alone. Prior to charging a battery with radio, turn
the radio off. To charge a battery, use the following
procedure: (Refer to Figure 1, page 8)
1. Plug the round end of the transformer cord into the
socket on the back of the charger.
2. Plug the transformer into the appropriate ac outlet.
The charger LED will blink green once to indicate
a successful power-up.
3. Insert a battery, or a radio with battery (radio
turned off), into the charger's pocket by:
a. aligning the groove on each side of the battery
with the corresponding raised rail on each side
of the charger pocket.
b. pressing the battery toward the rear of the
pocket
To Next Page
