4.6 Part Numbers
*For Part numbers of other variants please consult Level 1&2 parts list)
Item Part number Description
1. 20.F0075.014 System connector
2. 22.10128.006 SIM card connector
3. 22.80019.051 Vibrator motor
4. 23.40046.001 Speaker
5. 23.60016.041 Buzzer
6. 23.42007.031 Microphone
7. 25.90012.001 Antenna
8. 34.G0110.001 Holder vibrator
9. 34.G0510.002 Dome switches
10. 42.G0102.003 LCD Holder
11. 42.G0101.001 LCD cover
12. 47.G0101.001 Keypad
13. 47.G0101.011 Keypad (Chinese)
14. 47.G0104.001 Microphone holder
15. 47.G0109.001 Buzzer cap
16. 47.G0105.001 Speaker cushion
17. 56.07249.071 LCD module
18. 60.G0105.001 Volume-key switch
19. 60.G0109.003 Lower case
20. 60.G0108.003 Upper case(Blank)
21. 60.G0108.021 Upper case(Yellow)
22. 60.G0108.011 Upper case(Red)
23. 60.G0108.041 Upper case(Blue)
24. 60.G0108.051 Upper case(Silver)
25. 60.G0108.061 Upper case(Titanium)
26. 60.G0108.071 Upper case(Radar Blue)
27. 86.1A52P.3R5 Screw M1.6x6.5L
28. 55.G0501.006 Main board (PCB)
29. 50.25001.021 RF cable
30. 90.25030.001 Downloader + cable
* The numbers on this part list to not correspond with the part
numbers on the exploded diagram.
