Specifications (W370/W375) W370\W375
8 Aug.15, 2006
Transmitter Functions Specification
RF Power Output EGSM/GSM850: 32.5dBm (TYP),
DCS/PCS: 30dBm (TYP)
Output Impedance 50 ohm (TYP)
Spurious Emissions -36 dBm from 0.1 to 1GHz,
-30 dBm from 1 to 4GHz
Receiver Functions Specification
Receiver Sensitivity EGSM/GSM850: -107dBm,
DCS/PCS: -106dBm
RX Bit Error Rate (100K bits) type II <2%
Channel Hop Time 500 microseconds
Time to Camp Approximately 6~10 Second
Speech Coding Functions Specification
Speech Coding Type Regular pulse excitation/linear predictive
coding with long term prediction (PRE
LPC with LTP)
Bit Rate 13.0 Kbps
Frame Duration 20 ms
Block Length 260 bits
Classes Class 1 bits =182 bits;
Class 2 bits = 78 bits
Bit Rate with FEC Encoding 22.8 Kbps
