motortronics VMX-B Soft Start Packages - Page 7

7 REV-02 100418
Parameter
Description
Adjustment Range
Factory Setting
F052
Auto Reset Selected Trips
Auto Reset Disabled
0
Reset after Over Temperature Trip only
Reset after Over Current (Shear Pin) Trip only
Reset after Under Current Trip only
Reset after Phase Loss Trip only
Reset after Current Unbalance Trip only
Reset after Ground Fault Trip only
Reset after Short Circuit Trip only
Reset after OT Trip or Over/Under Current Trip
Reset after Phase Loss, Current Unbal, or GF Trip Reset after
all Except Short Circuit Trip
Reset after all Except GF or Short Circuit Trip
Reset after any Trip
1
2
3
4 (Default)
5
6
7
8
9
10
11
12
F053
Auto Restart Attempts
0=Disabled, 1-10 = # of Attempts
0
F054
Auto Restart Delay Readout
Readout only
F055
Coast Down Lockout Time Readout
Readout only
F056
Starts Per Hour Timer Readout
Readout only
F057
Starts Per Hour Readout
Readout only
F058
Time Value Between Starts Readout
Readout only
F059
Thermal Capacity to Start Readout
Readout only
F060
Aux Relay 1 setting
Run/Stop
1
F061
Aux Relay 2 setting
At Speed/Stop
2
F062
Aux Relay 3 setting
Any Trip
22
F063
Aux. Relay Delay Timer
0=Disabled or 1-999 seconds
0
F065
Communications
0=Disabled
1=Enabled(11bit)
2=Enabled(10 bit)
0:Disabled
F066
Baud Rate
4.8, 9.6, 19.2 KB
9.6
F067
Modbus Address
1-247
1
F068
Remote Starter Control from Communications
0=Disabled
1=Enabled w/Start PB
2=Enabled w/o Start PB
3=Enabled via Remote Jog Input
0
F070
Parameter Lock/ Level 1 Password
0=Disabled or 001-999
0
F071
System Clear / Factory Reset
0=Disabled, 1=Clear Lockouts
2=Reset to Factory Default
0
F073
Frame Rating
10-2000A
by model
F074
CT Value
10-2000
by model
F075
Year
2000-2047
2000
F076
Month
1-12
1
F077
Day
1-31
1
F078
Hour
0-23
0
F079
Minute
0-59
0
F080
Seconds
0-59
0
F081
Software rev # (info purposes only)
rev #
Rev #
F085
Fault History #1 (most recent fault code)
0=No Fault History, or Fault # 1-27
(full manual for fault code descriptions)
0
F086
Time Stamp Fault #1
00.00-23.59 (hh.mm)
00.00
F087
Date Stamp Fault #1
01.01-12.31 (MM-DD)
01.01
F088
Fault History #2 (previous fault code)
0=No Fault History, or Fault # 1-27
(full manual for fault code descriptions)
0
F089
Time Stamp Fault #2
00.00-23.59 (hh.mm)
00.00
F090
Date Stamp Fault #2
01.01-12.31 (MM-DD)
01.01
F091
Fault History #3 (oldest fault code)
0=No Fault History, or Fault # 1-27
(full manual for fault code descriptions)
0
F092
Time Stamp Fault #3
00.00-23.59 (hh.mm)
00.00
F093
Date Stamp Fault #3
01.01-12.31 (MM-DD)
01.01
F094
Run Time Hours
000.9-999.9 hours
0000
