motortronics VMX-B Soft Start Packages - Page 8

8 REV-02 100418
Parameter
Description
Adjustment Range
Factory Setting
F095
Run Time in 1,000s of hours
0000-9999K hours
0000
F096
Run Counts
0000-9999
000
F097
Run Counts in 10,000s of counts
0000-9999 (0001 would equal 10,000 counts)
000
F098
Phase Rotation Trip
0, 1 or 2
0=Disabled, 1=ABC, 2=ACB]
0
F099
Phase Rotation Trip Delay
1 - 3 seconds
1 Sec
F100
Phase Loss Trip Delay during Stop
0 - 20 seconds
[0 = Disabled]
1 Sec
F101
Phase Loss Trip Delay during Running
0 - 20 seconds
[0 = Disabled]
1 Sec
F102
Motor kW Trip
0 - 2
0 = Disabled
1 = Over kW Trip
2 = Under kW Trip
0
F103
Motor kW Trip Point
20 - 100% of full load KW
50(%)
F104
Motor kW Trip Delay Time
1 - 999 seconds
1
F105
Power Factor Trip Range
0, 1 - 3 [0=Disabled, 1=lag, 2=lead, 3= lead/lag]
0
F106
Power Factor Trip Point
.01 - 1
.50
F107
Power Factor Trip Delay Time
1 - 20 seconds
2 Sec
F108
Analog Output
0 - 12
[0: OFF; 1 - 12]
(See Table of Default Display)
OFF
F109
Analog Output 4mA
0 - 9999
0
F110
Analog Output 20mA
0 - 9999
9999
F111
Default Display
1-12 (See Table of Default Display)
10
F112
System Settings
Reserved for factory use
-
F113
Alternate functions for Ramp2/Jog inputs
Setting Dual Ramp Input Jog Input
0 Dual Ramp Jog
1 Dual Ramp Remote / Local
2 Dual Ramp Ext. Lockout N/O button
3 Dual Ramp Ext. Lockout N/C button
4 RESET Jog
5 RESET Remote / Local
6 RESET Ext. Lockout N/O button
7 RESET Ext. Lockout N/C button
7
