Motrex H100 User Manual

■ 8
4) Connect the HUD main cable to the HUD.
(When connecting the HUD main cable, make sure the thicker part does not get inside the
place for the cables as shown in the image below.)
5) Attach the HUD on the dashboard.
(Install the HUD on the cradle and remove the 3M tape to attach the HUD on the dashboard.)
(Choose the cradle of your preference between the adjustable type and the fixed type.)
6) Use the clips to organize the line.
Adjustable Type Fixed Type
* Above images are provided for reference.

Motrex H100 Specifications

General

Brand	Motrex
Model	H100
Category	Monitor
Language	English
