7
■
※ When the first OBD module is connected to the vehicle, the HUD will illuminate for 10 minutes.
Please set up the vehicle in the MOTREX HUD APP.
The HUD APP automatically switches off after 10 minutes without having to set up the vehicle, after
which the HUD must be switched on.
2. HUD Installation
Check where
the OBD
terminal is
1
Attach HUD to
the dashboard
5
Set the
HUD location
2
Organize
the cables
6
Embed the
HUD main cable
3
Connect the
OBD ll module
7
Connect the
HUD main cable
4
Connect the OBD ll
module with the
HUD main cable
8
1) Check where the OBD Ⅱ
terminal is.
(The location of the OBD terminal is
different by car.)
3) Embed the HUD main cable.
(Check the length of the main cable and then embed the HUD main cable.)
2) Decide where to install
the HUD.
(Decide the location and install. Order of
recommendation: 1, 2, 3)
To Next Page
