Mount-It! MI-384L - Page 10

10
6
-b
H
I
Wood Stud Mounting
6
-a
H
Install the assembled arm to the wall using the Lag Screws (#H) and Washers (#H) as shown.
Concrete/Brick Mounting
Insert the Concrete Anchors (#I) into the drilled holes, then install the assembled arm to
the wall using the Lag Screws (#H) and Washers (#H) as shown.
