20
EN
only be engaged when the
machine is stopped.
If the drive
pedal is used, whether forwards or
for reverse, when the parking brake
(4.5) is engaged, the engine stops.
.
4.33 L
EVER TO RELEASE THE HYDRO-
STATIC TRANSMISSION
This lever has two positions as
shown on the label:
«A» = Transmission engaged: for all usage conditions, when moving and during
cutting;
«B» = Transmission released: considerably reduces the effort required for moving
the machine by hand, with the engine turned off.
To avoid damaging the transmission unit, this operation must
be carried out only when the engine has stopped with the pedal (4.32) at position
«N».
IMPORTANT
NOTE
CONTROLS AND INSTRUMENTS
A
B
4.33
N
4.32
F
R
