MAINTENANCE
6.5 INFORMATION FOR SERVICE CENTRES
Below is a list of specifications for machine adjustments and instructions for disman-
tling and replacing the blades.
These operations must be carried out by a specialized Centre
only. Remove the ignition key before doing any adjustments or maintenance.
6.5.1 A
DJUSTMENTS

!
WARNING!
a) Brake:

➤
Mechanical
transmission:

➤
Hydrostatic
transmission:
b) Drive:

➤
Mechanical
transmission:

➤
Hydrostatic
transmission:
c) Blade engagement:

➤
Lever
engagement:

➤
Electromagnetic
engagement:
Element Position Position of controls Adjustment
47,5-49,5
45-47
4.5
4.5
A
4.5
A
4.5
114-116
109-111
Mod. 102 = 94-96
Mod. 122 = 92,5-93,5
Mod. 102 = 113-115
Mod. 122 = 90-91
B
4.7.1
B
B
