Centre line
Again, find another wood stud
Bolt Head UP!
CAUTION:
To avoid potential personal injury or property damage:
All 4 lag bolts MUST BE firmly tightened to prevent unwanted movement of the wall plate
assembly. Ensure the wall plate assembly is securely fastened to the wall before continuing on to
the next step.
To prevent the TV falling down, the Bolt Head Must Keep UP at this step!!
Bubble level
Stick
7/32"
(5.5mm)
No!
To Next Page
